Cisco WS-G5484 User Manual

6
Gigabit Interface Converter (GBIC) Module and Small Form-Factor Pluggable (SFP) GBIC Module Installation Information and Specifications
OL-5067-08
GBIC Module and SFP Module Overview
Table 3 provides power budget information for the SFP-GE-F, SFP-GE-L, SFP-GE-S, and SFP-GE-Z
modules.
Table 4 lists the GBIC module physical specifications and Table 5 lists the SFP module physical
specifications.
Table 3 SFP-GE-F, SFP-GE-L, SFP-GE-S, and SFP-GE-Z Module Transmit Power, Receive Power, and Power Budget
SFP Modules Transmit Power Receive Power Power Budget
Minimum Maximum Minimum Maximum
SFP-GE-F=
For 50/125 cabling
For 62.5/125 cabling
-23.5
-20
-14
-14
-33.5
-33.5
-11.8
-11.8
10 dB
13.5 dB
SFP-GE-L -9.5 dB
1
-11.5 dB
2
1. For fiber types 9/125 mm SMF.
2. For fiber types 62.5/125 mm MMF and 50/125 mm MMF.
-3 dB
3
3. For fiber types 9/125 mm SMF, 62.5/125 mm MMF, and 50/125 mm MMF.
-20 dB -3 dB 8.5 dB
4
and 10.5 dB
5
4. For fiber types 50/125 mm MMF and 62.5/125 mm MMF.
5. For fiber type 10 mm SMF.
SFP-GE-S -9.5 dB
6
6. For fiber types 50/125 mm, NA = 0.20 fiber and 62.5/125 mm, NA = 0.275 fiber.
-3 dB -17 dB 0 dB 7.5 dB
7
7. For fiber types 50/125 mm MMF and 62.5/125 mm MMF.
SFP-GE-Z 0 dB 5 dB -23 dB 0 dB -24 dB
Table 4 GBIC Module Specifications
Specification Description
Dimensions (H x W x D) 0.39 in. x 1.18 in. x 2.56 in.
(1 cm x 3 cm x 6.5 cm)
Connectors Multimode fiber-optic: SC-type connector
Single-mode fiber-optic: SC-type connector
Wavelength WS-G5484: 850 nm
WS-G5486: 1300 nm
WS-G5487: 1550 nm
Cabling distance
(maximum)
WS-G5484: 1804 feet (550 m)
WS-G5486: 6.2 miles (10 km)
WS-G5487: 43.5 to 62.1 miles (70 to 100 km)
Table 5 SFP Module Specifications
Specification Description
Dimensions (H x W x D) 0.33 in x 0.53 in x 2.22 in (8.5 mm x 13.4 mm x
56.5 mm)
Connectors Multimode fiber-optic: LC-type connector
Single-mode fiber-optic: LC-type connector
