11
B. Fasten the pressure cuff snugly.
a. Do not pull strongly on the pressure
cuff.
b. Do not make the pressure cuff too
tight.
c. Leave approximately 10 mm (0.4
inches) between the sleeve and the
bottom of the palm of your hand.
Figure No. 5.
* Figure No.5-1
135 ~ 195 mm
(5.3 ~ 7.7 inch)
A. Wrap the pressure cuff around the wrist.
a. The display of the unit should be
placed on the palm side of the wrist.
b. The wrist should be bare.
6. Attaching pressure cuff
* Figure No.5
10 mm
(0.4 inch)
*Note!
● Do not use this device if your wrist has any wound or injury.
● Do not wrap the cuff around any body part other than your
wrist.
