Citizen CL-E730 Programming Manual

CITIZEN Android Label Print SDK — Programming Manual
13
Methods (LabelDesign class)
No
Method
Description
1
LabelDesign
Constructor.
2
drawTextPtrFont
Draws text by using a printer device font.
3
drawTextDLFont
Draws text by using a downloaded font.
4
drawTextLocalFont
Draws text by using a font installed in the terminal.
5
drawNVBitmap
Draws a bitmap image stored in the flash memory of the printer.
6
drawBitmap
Draws a bitmap file in the computer.
7
drawBarCode
Draws a barcode.
8
drawMaxiCode
9
drawPDF417
10
drawDataMatrix
11
drawQRCode
12
drawAztec
13
drawGS1DataBar
14
drawLine
Draws a line.
15
drawRect
Draws a rectangular.
16
fillRect
Draws a rectangular filled with a specified pattern.
17
drawCircle
Draws a circle.
18
fillCircle
Draws a circle filled with a specified pattern.
19
drawPolygon
Draws a polygon.
20
fillPolygon
Draws a polygon filled with a specified pattern.
21
embedRawDesignCommand
Embeds raw printer commands.

Citizen CL-E730 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Core diameter	75 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Maximum roll diameter	200 mm
Supported paper width	12.5 - 118 mm
Ethernet LAN	Yes
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Display	LCD
Product color	Black
LED indicators	Status
Flash memory	16 MB
Internal memory	32 MB
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	100 - 230 V
Power consumption (standby)	2.9 W
Power consumption (printing)	72 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	458 mm
Width	250 mm
Height	261 mm
Weight	11000 g
