Citizen CL-E730 Programming Manual

CITIZEN Android Label Print SDK — Programming Manual
45
2.2.28 StopOffset property
Syntax
int StopOffset
Attribute
Read/Write
Description
Specifies the distance between paper sensor and cutter or peeler to change the print stop position.
Note that the initial values are calculated to stop paper at an appropriate position. An insufficient
value truncates the printed label, an exceeded value truncates the next label.
Media handling
Inch system
Metric system
Initial
value
Minimum
value
Max
value
Initial
value
Minimum
value
Max
value
None
0000
0000
9999
0000
0000
9999
Cutter
0100
0254
Peel Off
0050
0127
Tear Off
0070
0178
*0.01 inches or 0.1 mm
Setter method
int setStopOffset (int stopOffset)
Returns CLS_SUCCESS (0) on success. See "2.1 Return value" for the error codes.
Getter method
int getStopOffset ()
Returns the set value. If nothing has been set, it returns CLS_PROPERTY_DEFAULT(999999).
Example
int stopOffset;
printer.setStopOffset(240);
stopOffset = printer.getStopOffset();

Citizen CL-E730 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Core diameter	75 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Maximum roll diameter	200 mm
Supported paper width	12.5 - 118 mm
Ethernet LAN	Yes
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Display	LCD
Product color	Black
LED indicators	Status
Flash memory	16 MB
Internal memory	32 MB
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	100 - 230 V
Power consumption (standby)	2.9 W
Power consumption (printing)	72 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	458 mm
Width	250 mm
Height	261 mm
Weight	11000 g
