156
In the event of a breakdown
Passenger compartment fuses
Fuses
F
Amps
A
Allocation
1 - Free
2 20 Heated seats
3 - Free
4 15
Folding rearview
mirror relays
5 15
Refrigeration
equipment socket
relay
Towing/towbar/
coachbuilder/platform cab
fuses
The designations given are only indicative, as
this additional box relates to other information
which depends on converter/coachbuilder, for
which the handbook cannot provide technical
support.
Fuses F Amps A Allocation
1 15 Free
2 15 Contact relay, optional generator
3 15 12
V trailer power supply
4 15 Continuous power supply for converters/coachbuilders
5 40 Hazard warning lamps
