41
3
Ease of use and comfort
F To return the backrest to the sitting position,
pull the tongue and guide the backrest until
it locks.
During manipulations, take care not to jam the
tongue under the seat.
Storage compartment under the seat
Each time you lock the seat in the sitting
position, make sure that passengers have
access to the seat belt end pieces and the
associated straps.
Side seat
Retractable position
When retracted, the maximum weight on the
backrest is 50
kg.
To return the seat to the sitting position, lift the
backrest until the seat locks into position on
the floor.
F
Lift the central seat to access the storage
compartment. This space can be secured
by fitting a padlock (not supplied).
Its backrest is fitted with a metal shell.
F Pull the tongue on the top edge of the seat
near the head restraint to tilt and guide the
assembly.
It is placed in the floor of the front seat and
thus forms a continuous flat floor with the load
space.
This position allows the transport of loads up
to 3
m long inside the vehicle with the doors
closed (3.25 m on long wheelbase versions).
Folded position
This position allows the transport of high loads
inside the cab.
To return the seat to the sitting position, push
on the yellow crank under the seat and lower
the assembly until the seat locks into position
on the floor.
F
Lift the yellow crank at the base of the
seat to unlock and lift the assembly into
the folded position (seat raised against the
backrest) until it locks.
