42
Ease of use and comfort
F Lift the grey control bar located on the back
of the seat.
F Tilt the assembly forwards.
Rear bench seat
Head restraint
Fully folded position
Example of operations for the 1/3 section. They
are identical for 2/3 section.
F
Place the head restraints in the low position.
F
If necessary, move the front seats forward.
The 1/3-2/3 rear bench seat is fitted with
rounded head restraints.
Each 1/3-2/3 section can be folded into the fully
folded position, then removable individually.
High position: lift and raise the head restraint.
Low position: press on the head restraint to
lower it.
To remove the head restraint after raising it,
press the tab and lift the head restraint.
To re-install the head restraint, engage the rods
of the head restraint in the holes, keeping it in
line with the backrest.
F
Press on the grey control located on the top
of the backrest.
F
Fold the backrest onto the seat.
