ENGINE
81
Setting the valve timing.
Peg :
- The engine flywheel, tool [3]. (From under the vehicle).
- The camshaft, tool [5].
Loosen :
- The three screws (21).
- The screw (19) of the tensioner roller (20).
- Remove the timing belt (22).
Checks.
IMPERATIVE : Just before refitting, carry out the checks below:
Check that :
- The rollers (20), (23) and the water pump turn freely (without play or tightness).
- There are no traces of oil (on camshaft or crankshaft).
- There are no leaks of coolant fluid (from water pump).
- Replace defective components (if necessary).
CHECKING AND SETTING THE VALVE TIMING
Engines : RHY - RHZ
B1EP152D
B1BP282C
