Up and Down request
Access from the paddle
Push to Downshift
Pull to Upshift
Neutral request
Active by pushing the lock button
and Up or Down request
Disable over 30km/h, gear > 1
And RPM > 2500
Reverse request
Active by pushing the lock button and Down
request
Disable over 10km/h or 2500rpm
Reverse disengaged by Neutral request.
Engine Crank (Oil pressure build)
Active if DIM141 is not connected by
pressing ‘start’ button
Kill Engine
Active if Power is switched OFF
Vehicle Maps
Few Vehicle maps will be available
on the center panel in STAGE mode only
(see chart opposite).
Start Assistance System
See page 17
2. Steering Wheel Management
9
System User Guide - 03.12.14
Steering Wheel Input Signal
Tarmac Gravel
S0 Torque reduced (low grip) Torque reduced (low grip)
S1
Intermediate Torque
SAS (standard grip)
Intermediate Torque
SAS (standard grip)
S2
Full power
SAS (high grip)
Full power
SAS (high grip)
