8. Calibration
18
System User Guide - 03.12.14
Pedal/Throttle Calibration
Before
1. Engine Stopped
2. Gearbox in Neutral
Process
1. CAR Main SW OFF
2. Switch Power ON
3. Push full throttle
4. Then switch Main Switch ON
5. Stay that way until a message appears on Dash
6. Follow instructions
If the process is aborted, the dash will show you a KO message
Must be done after
1. Throttle or pedal has been changed
2. Engine has been changed
3. ECU has been changed
