9. Diagnostic
20
System User Guide - 03.12.14
Clutch Warning
Appear on Road and Stage pages only
Appear if clutch pressure is not enough to change gears properly.
Driver is advised to use Clutch pedal to change gears
Engine Warning
Ignition plug not connected:
This icon will appear in Mechanic Diagnostic page with the cylinder number.
Synchronisation information
In case of lost synchronization, those icons will appear into Mechanic Diagnostic page with a name
related to it
In case of weird behavior of crank signal
Rpm=0 and start button activated, a alarm will be Raised
Outputs Warnings
In case of current protection, an alarm will be raised.
Then before any power cycle, go to Mechanic Diagnostic page to check what has been switched off
Bosch Element
Reverse Light
Stop Lights
Crank or Cam &
Lambda
Wiper
Radio
Rear Lights
Lap Marker
Map Lights
Rear Lights
Map Lights
