Checks
Bonnet
Protects the components of the engine and provides access for checking levels.
Opening
) Open the front left door.
) Pull the interior release lever A , located at
the bottom of the door aperture.
) Push the exterior safety catch B to the left
and raise the bonnet.
) Unclip the bonnet stay C from its housing,
holding it by its foam protection.
) Fix the stay in the notch to hold the bonnet
open.
The location of the interior release lever
prevents opening of the bonnet while
the front left door is closed.
When the engine is hot, handle the
exterior safety catch and the stay
with care.
Before doing anything under the
bonnet, switch off the Stop & Start
system to avoid any risk of injury
resulting from an automatic change to
START mode.
