Practical information
Indications given by the LEDs on the control unit
POWER LED
CHARGING
LED
FAULT LED Description
On for ½ sec. On for ½ sec. On for ½ sec. All of the LEDs come on for ½ second to verify
that they work, when the charging cable is
plugged into the power point.
On Off Off The charging cable is plugged into the power
point. If the Type 2 connector is in the vehicle's
charging socket, the charge has finished.
On On Off The vehicle's battery is charging.
On Off On/flashing Fault with the charging cable. Stop using
the charging cable immediately and
contact CITROËN ASSISTANCE.
Off Off Off No electrical power supply is detected at the
power point by the charging cable. Check
the circuit breaker for the power point. If the
power point electrical supply is correct and
all the LEDs do not light up for half a
second
to verify that they are working properly,
the charging cable may be damaged. Stop
using it immediately and contact CITROËN
ASSISTANCE.
Comparison of charging times
Charging type
Estimated charging
time (0-100%)
Charging point: 16 A 8 to 9 hours
230 V/16 A
power point 10 A
consumed
13 hours
When charging the vehicle, particularly
at the roadside, be especially careful of
children when handling the cable and the
charging point.
The cable reel can operate sharply and
cause injury.
Children could trap their fingers in the
charging point closing mechanism.
