6
Accessories (Optional)
Exhaust duct set (Optional)
Note
The above gure shows a state in which mounted the exhaust duct to the dryer body.
The exhaust duct and mounting screw set are available.
Model No.
Applicable model
Dimension (mm)
A
B C
D
GX-KFL-614457 GX8265D 350 872 98 1054
GX-KFL-614458 GX8275D 400 758 225 1229
GX8200 Series
Flow characteristics
GX-KFL-614725 (Applicable model GX8295D)
B C
A
D
Suction
Exhaust
Exhaust duct set
(Oblique line area)
Exhaust Exhaust
Suction
Front
697 662
Exhaust duct set
（
Oblique line area
）
1275
