299 216.0 - RHB MEDION 340 - 310 1.1.3
General
Explanation of pictorials
The present CLAAS REPAIR MANUAL uses some
pictorials from the "Overview of pictorials DIN 30600"
issued by the DIN (German Standardisation Institute).
The user will easily remember the meanings of these
pictorials. They are intended to assist in identifying fre-
quently recurring handling processes and information
in the pictures quickly.
Remove, dismantle Grease
Prevent material
damage
Disassemble Oil Use special tool
Assemble Adjust
Drain,
drain opening
Install, fit Eye, check, inspect Fill in, filler opening
Mark Unlock, safeguard Overflow
Balance
Safeguard, glue, seal
with a liquid
Vent
Reusable with
reservations
Support, prop up
Replace with every
assembly
Observe the direction
of installation
