11.2 ENGINEERING DATA
FILOX Series Filters CF1044 to CF 1465
Model CF1044 CF1248 CF1354 CF1465 CF1665
Valve WS1 WS1 WS1 WS1 WS1.5
Filter Vessel 1054 1248 1354 1465 1665
Parameter Unit
Height of
Filter
Mm 1601 1458 1601 1984 1984
Diameter of
Filter
Mm 254 305 331 356 407
Height of
Valve
mm 170 170 170 170 170
Filter Inlet
Conn.
Inches
BSPM
1 1 1 1 1.5
Filter Outlet
Conn.
Inches
BSPM
1 1 1 1 1.5
Drain Conn. Inches
BSPM
3/4 3/4 3/4 ¾ 1
Qty. of
Gravel
Bags 0.25 0.5 0.75 1.5 1.5
Qty of Filox Bags 2 3 4 5 8
Electrical
Power
Watts 1.2 1.2 1.2 1.2 1.2
PRESSURE 1.7 Bar MAXIMUM OPERATING TEMPERATURE 45.0C
HEADROOM - Allow 100 mm greater than overall height.
