English
21 CX501E
Operations Common to Each Mode
● Setting the contrast
You can adjust the display contrast to match the
angle of installation of the unit.
∗ The factory default setting is “10”.
(Adjustment level: 1 to 16)
2-1. Select “CONTRAST”.
3-1. Turn the [ROTARY] knob to adjust the
contrast.
● Setting the button illumination
2-1. Select “COLOR”.
3-1. Turn the [ROTARY] knob to select the
color type.
• Setting COLOR SCAN mode
As selecting “CLR SCAN”, the color
automatically changes.
∗ The factory default setting is “CLR SCAN”.
∗ After 3 seconds the color changes to the other.
• Setting USER mode
The factory default setting is “RED 8” (red),
“GREEN 8” (green), “BLUE 8” (blue).
As selecting “USER COLOR 1, 2, 3”, press the
[ROTARY] knob to enter the setting.
1. Press the [x] or [v] to select “RED”,
“GREEN” or “BLUE”.
2. Turn the [ROTARY] knob to select from 0 to
8.
3. Press and hold the [ROTARY] knob for
2 seconds or longer to store the color in
memory and cancel the setting mode.
● Setting the anti-theft function (CATS)
“CATS” is the acronym of “Clarion Anti-Theft
System”. When you set a PIN code (called as
“Personal Code”), a theft is prevented by
disabling the operation of the unit at the theft.
• Setting your Personal Code
2-1. Select “CODE”.
3-1. Press the [ROTARY] knob.
The set personal code screen appears.
4-1. Press the [DIRECT] buttons [1]-[6] to enter
your desired 4-digit Personal Code.
5-1. Press and hold the [ROTARY] knob
(2 sec.).
The entered Personal Code will be set, and
it will return to the previous screen.
Note:
• Write down your Personal Code in case you
forget it.
•
Erasing the Personal Code
2-1. Select “CODE”.
3-1. Press the [ROTARY] knob.
The ERASE PERSONAL CODE screen
appears.
4-1. Enter the Personal Code currently.
5-1. Press and hold the [ROTARY] knob
(2 sec.) or longer.
Entering a Personal Code mode is
cancelled.
• When the ENTER PERSONAL CODE
screen appears
The ENTER PERSONAL CODE screen will be
displayed when turning the ACC power on after
performing the following operations:
• The car battery was replaced.
• The backup power was cut off.
• The [RESET] button was pressed.
Note:
• If you have lost your Personal Code, please
contact Clarion customer service.
1. Enter your Personal Code currently set.
2. When the correct Personal Code is entered,
the unit will restart from the initial startup
screen.
To change adjustment setting
1. Press and hold the [DISP] button (1 sec.)
to switch to the adjustment selection
display.
2. Press the [x] or [v] button to select
the “item name”.
“CONTRAST” ↔ “COLOR” ↔ “CODE” ↔
“SCRN SVR” ↔ “SCROLL” ↔
“DIMMER” ↔ “BLINKLED” ↔
“REAR/S-W” ↔ “INT-SW” ↔ “RESET”
3. Turn the [ROTARY] knob to select the
“desired setting value”.
∗ In the case of display blinking “ENT”, you
can press the [ROTARY] knob to adjust the
setting value.
∗ After completing settings, press the [DISP]
button to return to the previous mode.
CX501E_EN.book Page 21 Thursday, November 11, 2010 1:16 PM
