Clarion DB189RMP Service Manual

pin 38
:
DVDD15
:
O
:
Digital circuit power source capacitor earth terminal.
pin 39
:
VVDD3
:
-
:
Building PLL into power supply terminal.
pin 40
:
VVSS3
:
-
:
Connect to GND.
pin 41
:
DVDD
:
-
:
Digital system power supply terminal.
pin 42
:
DVSS
:
-
:
Digital system earth terminal, Must connect to 0V.
pin 43
:
CE
:
IN
:
Host IF:Enable signal input terminal.
pin 44
:
CL
:
IN
:
Host IF:Data transfer clock input terminal.
pin 45
:
DIN
:
IN
:
Host IF:Data input terminal.
pin 46
:
DO
:
O
:
Host IF:Data output terminal.
(Nch opening drain output)
The external of the Pull-Up resistance is necessary.
pin 47
:
RESB
:
IN
:
LIS reset input terminal.
Once you turn on the power supply , It turn to "L" .
pin 48
:
REG_READYO
:
O
:
Host IF:REG_READY output.
(Nch opening drain output)
The external of the Pull-Up resistance is necessary.
pin 49
:
SUB_READYO
:
O
:
Host IF:SUB_READYSY output.
(Nch opening drain output)
The external of the Pull-Up resistance is necessary.
pin 50
:
CD_MUTEO
:
I/O
:
Output L fixation after reset is released.
Host IF:CD_MUTE request output.
(Nch opening drain output)
The external of the Pull-Up resistance is necessary.
pin 51
:
LOW_BAT1
:
I/O
:
Host IF:Standby control input.
pin 52
:
CONT
:
I/O
:
Connect to GND.
pin 53
:
MODE
:
IN
:
Setting Input terminal, Must connect to DVDD.
pin 54
:
STREQ
:
I/O
:
Stream data demand signal output terminal.
pin 55
:
STCK
:
I/O
:
Stream data bit clock input terminal.
pin 56
:
STDATA
:
I/O
:
Stream data input terminal.
pin 57
:
TEST
:
IN
:
Connect to GND.
pin 58
:
DATA
:
O
:
Lch/Rch channel data output terminal.
pin 59
:
DATACK
:
O
:
Bit clock output terminal.
pin 60
:
LRSY
:
O
:
Lch/Rch clock output terminal.
pin 61
:
VVDD2
:
-
:
Building VCO into Power supply terminal.
pin 62
:
VPREF2
:
IN
:
Building VCO into oscillation cooking stove setting
input terminal.
pin 63
:
VCOC2
:
IN
:
Building VCO into Control setting voltage terminal.
pin 64
:
VPDOUT2
:
O
:
Building VCO into control output terminal.
pin 65
:
VVSS2
:
-
:
Building VCO into earth terminal, Must connect
to 0V.
pin 66
:
DVDD15
:
O
:
Digital circuit power source capacitor earth terminal.
pin 67
:
DVSS
:
-
:
Digital system power supply terminal, Must
connect to 0V.
pin 68
:
DVDD
:
-
:
Digital system power supply terminal
pin 69
:
DOUT
:
O
:
Digital out output terminal, EIAJ format.
pin 70
:
AMUTEB
:
O
:
CD_MUTE0 signal output terminal.
pin 71
:
XVSS
:
-
:
Connect to GND.
pin 72
:
XOUT
:
O
:
16.9344MHz departure pendulum Connected
terminal.
pin 73
:
XIN
:
IN
:
16.9344MHz departure pendulum Connected
terminal.
pin 74
:
XVDD
:
-
:
Oscillation circuit Power supply terminal.
pin 75
:
LRVDD
:
-
:
LR channel power supply terminal.
pin 76
:
LCHO
:
O
:
L channel output terminal.
pin 77
:
LRREF
:
O
:
LR channel Reference output terminal.
pin 78
:
RCHO
:
O
:
R channel output terminal.
pin 79
:
LRVSS
:
-
:
Connect to GND.
pin 80
:
SLCO
:
O
:
Slice label control output terminal.
051-6095-00 LC75857W
CMOS IC 1/3, 1/4 Duty LCD Display
Drivers with Key Input Function
Terminal Description
pin 1
:
P1/S1
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 2
:
P2/S2
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 3
:
P3/S3
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 4
:
P4/S4
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 5
:
S5
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 6
:
S6
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 7
:
S7
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 8
:
S8
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 9
:
S9
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 10
:
S10
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 11
:
S11
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 12
:
S12
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 13
:
S13
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 14
:
S14
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 15
:
S15
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 16
:
S16
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 17
:
S17
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 18
:
S18
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 19
:
S19
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 20
:
S20
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 21
:
S21
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 22 S22
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 23
:
S23
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 24
:
S24
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 25
:
S25
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 26
:
S26
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 27
:
S27
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 28
:
S28
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 29
:
S29
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 30
:
S30
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 31
:
S31
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 32
:
S32
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 33
:
S33
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 34
:
S34
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 35
:
S35
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 36
:
S36
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 37
:
S37
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 38
:
S38
:
O
:
Segment outputs for displaying the display data
transferred by serial data input.
pin 39
:
COM4/S39
:
O
:
Common driver outputs.
pin 40 COM3 : O
:
Common driver outputs.
pin 41
:
COM2
:
O
:
Common driver outputs.
pin 42
:
COM1
:
O
:
Common driver outputs.
pin 43
:
KS1/S40
:
O
:
Key scan outputs.
pin 44
:
KS2/S41
:
O
:
Key scan outputs.
pin 45
:
KS3/S42
:
O
:
Key scan outputs.
pin 46
:
KS4
:
O
:
Key scan outputs.
pin 47
:
KS5
:
O
:
Key scan outputs.
pin 48
:
KS6
:
O
:
Key scan outputs.
pin 49
:
KI1
:
IN
:
Key scan inputs.
pin 50
:
KI2
:
IN
:
Key scan inputs.
pin 51
:
KI3
:
IN
:
Key scan inputs.
pin 52
:
KI4
:
IN
:
Key scan inputs.
pin 53
:
KI5
:
IN
:
Key scan inputs.
pin 54
:
VDD
:
-
:
Logic block power supply connection.
pin 55
:
VLCD
:
-
:
LCD driver block power supply connection.
pin 56
:
VLCD1
:
IN
:
Used for applying the LCD drive 2/3 bias voltage
externally.
pin 57
:
VLCD2
:
IN
:
Used for applying the LCD drive 1/3 bias voltage
externally.
pin 58
:
VSS
:
-
:
Power supply connection. Connect to ground.
pin 59
:
TEST
:
IN
:
This pin must be connected to ground.
pin 60
:
OSC
:
I/O
:
The OSC pin can be used to form an oscillator
circuit with an external resistor and an external
capacitor.
pin 61
:
DO
:
O
:
Serial data interface connections to the controller.
pin 62
:
CE
:
IN
:
Serial data interface connections to the controller.
pin 63
:
CL
:
IN
:
Serial data interface connections to the controller.
pin 64
:
DI
:
IN
:
Serial data interface connections to the controller.
:
:
-5-
DB188/189RMP/DB189RGMP
