Clarion DPX1001.2 User Manual

Owner’s Manual
7
Figure 4 - In this application, the amplifier is used in stereo and drives two
full-range (or satellite or subwoofer) speakers. NOTE: A passive crossover
must be used with satellite speakers. Minimum load in the stereo mode is
1ohm.
2-Channel Full Range, Satellite, or Subwoofer Stereo System
Set Amp Mode as shown
Set Amp Mode as shown;
adjust FREQ to speaker
specifications.
Set Amp Mode as shown;
adjust FREQ to speaker
specifications

Clarion DPX1001.2 Specifications

General

Brand	Clarion
Model	DPX1001.2
Category	Amplifier
Language	English
