Clarion DRX6575z User Manual

DRX6575z 9
Functions of Remote Control Unit Buttons
* Some of the corresponding buttons on the source unit and remote control unit have different functions.
, FUNC
- BAND
DISC UP
PROG
TOP
. VOLUME
/ SEARCH
: PLAY/PAUSE
; MUTE
< ISR
= DISP
> SCN
PS/AS
? RPT
BLS
@ RDM
DOLBY NR
MONI
Turns power on and off. When pressed and held for 1 second: Turns power off.
Switches among radio, CD, CD changer, MD changer and TV.
Button
Mode
Radio CD
CD changer
MD changer
Switches reception
band.
Plays the first track.
Top play.
Moves the next disc
in increasing order.
Increases and decreases volume (in all modes).
Moves preset
channels up and
down.
No function.
Moves tracks up
and down.
When pressed and
held for 1 second:
Fast-forward/
fast-backward.
Switches between
playback and pause.
Moves tracks up
and down.
When pressed and
held for 1 second:
Fast-forward/
fast-backward.
Switches between
playback and pause.
Turns mute on and off.
Preset scan.
When pressed and
held for 2 seconds:
Auto store.
No function.
No function.
Scan play.
Repeat play.
Random play.
Scan play.
When pressed and
held for 2 seconds:
Disc scan play.
Repeat play.
When pressed and
held for 2 seconds:
Disc repeat play.
Random play.
When pressed and
held for 2 seconds:
Disc random play.
TV
Moves preset
channels up and
down.
No function.
Switches reception
band.
Preset scan.
When pressed and
held for 2 seconds:
Auto store.
No function.
Switches between
TV and VTR.
Recalls ISR radio station in memory.
Press and hold for 2 seconds or longer: Stores current station into ISR memory (radio
mode only).
Switches among main display, sub display and clock display.

Clarion DRX6575z Specifications

FM Tuner

frequency range	87.9 MHz to 107.9 MHz
usable sensitivity	11 dBf
50dB quieting sensitivity	17 dBf
alternate channel selectivity	75 dB
stereo separation (1 kHz)	35 dB
frequency response (±3 dB)	30 Hz to 15 kHz

AM Tuner

frequency range	530 kHz to 1710 kHz
usable sensitivity	25 µV

CD Player

system	Compact disc digital audio system
usable discs	Compact disc
frequency response (±1 dB)	10 Hz to 20 kHz
signal to noise ratio (1 kHz)	100 dB
dynamic range (1 kHz)	95 dB
harmonic distortion	0.01%

Audio

maximum power output	160 W (40 W × 4 ch) (EIAJ)
continuous average power output	14 W × 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
bass control action (30 Hz)	±15 dB
treble control action (10 kHz)	±10 dB
line output level (CD 1 kHz)	4 V

General

power supply voltage	14.4 V DC (10.8 to 15.6 V allowable), negative ground
current consumption	Less than 15 A
speaker impedance	4 Ω (4 Ω to 8 Ω allowable)
weight of source unit	3.75 lb. (1.7 kg)
weight of remote control unit	1 oz. (30 g) (including battery)
dimensions of source unit	7" (Width) × 2" (Height) × 6-1/8" (Depth) [178 (W) × 50 (H) × 155 (D) mm]
dimensions of remote control unit	1-3/4" (Width) × 4-5/16" (Height) × 1-1/8" (Depth) [44 (W) × 110 (H) × 27 (D) mm]
