Clarion DRX9255EXL Service Manual

- 24 -
1 HBS-433-100 DRIVE UNIT 1
1-1 013-7100-00 LIMIT SWITCH 1
1-2 620-0198-03 CLAMPER PLATE 1
1-3 620-0491-03 SPRING PLATE 1
1-4 620-0690-00 RATTLE PLATE 1
1-5 621-0205-02 CLAMPER PLATE 1
1-6 621-0251-03 LOCK LINK 1
1-7 621-0252-03 DISC STOPPER 1
1-8 621-0253-02 MOTOR HOLDER 1
1-9 621-0255-02 SECOND GEAR 1
1-10 621-0257-25 SCREW HOLDER 1
1-11 621-0357-03 PICKUP GUIDE 1
1-12 621-0358-02 LS-HOLDER-F 1
1-13 621-0359-02 LS-HOLDER-R 1
1-14 622-1073-02 CLAMPER ROLLER 1
1-15 714-2003-81 MACHINE SCREW (M2X3) 10
1-16 716-0675-00 SCREW (M2X5.5) 2
1-17 716-1468-00 SCREW (M2X2.5) 2
1-18 716-1555-00 WAVE SCREW (φ2X8) 1
1-19 716-1733-00 SCREW (M1.7X2.3) 2
1-20 732-2004-11 SEMS SCREW (M2X4) 2
1-21 739-1735-17 PRECISION SCREW(M1.7X3.5) 2
1-22 750-3097-03 CLAMPER SPRING 1
1-23 750-3098-00 L-LINK SPRING 1
1-24 750-3099-00 ES-SPRING 1
1-25 746-0761-00 WASHER 2
1-26 816-2372-00 VINYL COAT WIRE(BLU) 1
1-27 816-2373-00 VINYL COAT WIRE(WHT) 1
1-28 966-0314-01 STOP LINK ASSY 1
1-29 966-0447-06 DR-PLATE ASSY 1
1-30 966-0448-01 SIDE PLATE ASSY 1
1-31 966-0449-04 CLAMP LINK ASSY 1
1-32 969-0005-00 PICKUP UNIT ASSY 1
1-33 HBS-432-100 LS-GEAR ASSY 1
1-34 SMA-146-100 MOTOR ASSY(SLED) 1
1-35 SMA-151-100 MOTOR ASSY(SPINDLE) 1
2 966-0308-11 CHASSIS ASSY 1
3 966-0309-05 L-DISC-G-ASSY 1
4 966-0310-06 SFT-P-CH-ASSY 1
5 966-0312-06 SHIFT-P-ASSY 1
6 966-0358-01 DRIVE-L-PL-ASSY 1
7 966-0359-03 SIDE-L-PL-ASSY 1
8 013-3879-01 CHUCKING SWITCH 1
9 039-0586-01 CHUCKING SW PWB 1
(WITHOUT COMPONENT)
10 039-0588-01 SENSOR PWB 1
(WITHOUT COMPONENT)
11 060-0252-01 PHOTO TR (PT4850F) 3
12 345-7513-01 CLAMPER SHEET 1
13 345-7514-00 S-PWB-SHEET 1
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
14 620-0485-04 FRONT PLATE 1
15 620-0488-01 S-L-LINK PLATE 1
16 620-0489-02 MOTOR PLATE 1
17 620-0492-01 MOTOR BRACKET 1
18 620-0691-05 MECHA BRACKET 1
19 621-0402-02 U-DISC GUIDE 1
20 621-0243-02 ROLLER SLEEVE 2
21 621-0248-07 RACK GEAR 1
22 621-0249-02 ROLLER GEAR 1
23 621-0250-21 DAMPER HOLDER 4
24 621-0258-03 LOADING ROLLER 2
25 622-1072-05 ROLLER SHAFT 1
26 622-1219-01 SHIFT ROLLER 1
27 629-0058-00 DAMPER-DL 4
28 714-2003-81 MACHINE SCREW(M2X3) 8
29 714-2603-81 MACHINE SCREW(M2.6X3) 5
30 716-1468-00 SCREW (M2X2.5) 2
31 716-1507-00 SCREW (M2X3) 2
32 716-1670-00 SCREW (M2X4) 6
33 716-1677-00 SCREW (M2X5) 1
34 716-1704-00 SCREW (M2X7) 1
35 716-1742-00 SCREW (M2X5) 1
36 743-1500-10 E-RING 3
37 746-0712-03 WASHER 1
38 746-0762-00 WASHER 1
39 746-0877-02 WASHER 2
40 750-3090-02 RO-SPRING-L 1
41 750-3091-03 RO-SPRING-R 1
42 750-3092-03 SHIFT SPRING 1
43 750-3094-00 S-ARM SPRING 1
44 750-3096-01 DR-SPRING-R 1
45 750-3098-00 L-LINK SPRING 1
46 750-3164-00 DR-SPRING-LR 1
47 750-3188-00 DR-SP-F-B 1
48 750-3189-00 SIDE-L-SPRING 1
49 750-3201-00 DR-SPRING-F-R 1
50 750-3202-00 CENTER SPRING-B 1
51 800-4904-60 VINYL COAT WIRE(BLK) 1
52 800-4910-60 VINYL COAT WIRE(BLK) 1
53 801-4910-60 VINYL COAT WIRE(BRN) 1
54 802-4904-60 VINYL COAT WIRE(RED) 1
55 802-4910-60 VINYL COAT WIRE(RED) 1
56 804-4910-60 VINYL COAT WIRE(YEL) 1
57 HBS-430-100 GEAR-SUB-ASSY 1
58 HBS-435-100 PWB ASSY 1
(WITH COMPONENT)
59 SMA-147-100 MOTOR ASSY(LOADING) 1
60 001-0563-00 DIODE 3
