Clarion DRX9255EXL Service Manual

- 7 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Note) Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
■ELECTRICAL PARTS LIST
Main PWB section(B1)
ANT1 092-4000-50 ANT RECEPT
ANT2 092-3101-00 ANT RECEPT
BL1 880-1950B AM/FM TUNER
C1 176-1011-00 100pF CH
C2 176-1011-00 100pF CH
C3 176-3301-00 33pF CH
C4 176-3301-00 33pF CH
C5 178-1042-78 0.1μF
C6 178-1042-78 0.1μF
C7 183-1053-61 50V1μF
C8 183-6843-61 50V0.68μF
C9 183-4743-61 50V0.47μF
C10 178-1032-78 0.01μF
C11 183-4763-31 16V47μF
C12 178-2232-78 0.022μF
C13 183-1063-31 16V10μF
C14 178-1032-78 0.01μF
C15 178-2232-78 0.022μF
C17 183-1053-61 50V1μF
C18 176-1011-00 100pF CH
C19 176-1011-00 100pF CH
C20 176-1011-00 100pF CH
C21 176-1011-00 100pF CH
C22 176-1501-00 15pF CH
C23 176-1801-00 18pF CH
C24 178-2232-78 0.022μF
C25 183-4763-11 6.3V47μF
C26 178-1032-78 0.01μF
C27 183-3353-61 50V3.3μF
C30 178-4732-78 0.047μF
C31 183-1073-21 10V100μF
C32 183-4763-31 16V47μF
C45 178-1032-78 0.01μF
C46 178-4732-78 0.047μF
C47 183-1063-31 16V10μF
C48 178-1032-78 0.01μF
C49 178-1022-78 1000pF
C50 178-2732-78 0.027μF
C51 178-2732-78 0.027μF
C52 178-6832-78 0.068μF
C55 176-1011-00 100pF CH
C56 178-1032-78 0.01μF
C57 178-2232-78 0.022μF
C58 178-2232-78 0.022μF
C200 183-4763-11 6.3V47μF
C201 183-2263-31 16V22μF
C203 178-2232-78 0.022μF
C204 042-0505-81 10V22μF
C205 172-4731-11 0.047μF
C206 183-1053-61 50V1μF
C207 172-1041-11 0.1μF
C208 184-4773-31 16V470μF
C209 183-1053-61 50V1μF
C210 183-2263-11 6.3V22μF
C211 178-4732-78 0.047μF
C212 183-4763-31 16V47μF
C213 042-0505-81 10V22μF
C214 178-1032-78 0.01μF
C215 178-1032-78 0.01μF
C216 176-1011-00 100pF CH
C218 176-1011-00 100pF CH
C219 176-1011-00 100pF CH
C220 176-1011-00 100pF CH
C221 176-1011-00 100pF CH
C222 178-1032-78 0.01μF
C223 176-1011-00 100pF CH
C224 183-1073-21 10V100μF
C226 178-2232-78 0.022μF
C227 160-1022-05 1000pF
C228 178-1022-78 1000pF
C229 178-1022-78 1000pF
C230 178-2732-78 0.027μF
C232 178-2232-78 0.022μF
C236 178-1032-78 0.01μF
C237 176-1011-00 100pF CH
C300 183-1063-31 16V10μF
C301 178-1042-78 0.1μF
C302 183-2253-62 50V2.2μF
C303 183-3343-61 50V0.33μF
C304 176-1211-00 120pF CH
C305 176-2201-00 22pF CH
C306 178-1042-78 0.1μF
C316 183-4753-51 35V4.7μF
C317 178-1042-78 0.1μF
C318 183-2253-62 50V2.2μF
C320 183-1063-31 16V10μF
C321 176-1211-00 120pF CH
C322 176-2201-00 22pF CH
C323 178-1042-78 0.1μF
C338 182-1073-33 16V100μF
C339 182-1073-33 16V100μF
C340 183-4763-11 6.3V47μF
C341 183-2263-31 16V22μF
C342 178-1042-78 0.1μF
C343 183-4753-51 35V4.7μF
C344 183-1063-31 16V10μF
C345 183-4753-51 35V4.7μF
C346 183-1063-31 16V10μF
C347 183-1053-61 50V1μF
C348 183-2263-31 16V22μF
C349 178-1042-78 0.1μF
C352 178-1032-78 0.01μF
C353 176-1211-00 120pF CH
C354 176-1211-00 120pF CH
C450 183-1063-31 16V10μF
C451 178-1042-78 0.1μF
C452 176-3301-00 33pF CH
C453 176-3301-00 33pF CH
C454 178-1042-78 0.1μF
C455 183-2263-31 16V22μF
C456 183-2263-31 16V22μF
C457 183-1063-31 16V10μF
C470 183-1063-31 16V10μF
C471 178-1042-78 0.1μF
C472 176-3301-00 33pF CH
C473 176-3301-00 33pF CH
C474 178-1042-78 0.1μF
C475 183-2263-31 16V22μF
C476 183-2263-31 16V22μF
C477 183-1063-31 16V10μF
C478 178-1032-78 0.01μF
C479 178-1022-78 1000pF
C511 183-3353-61 50V3.3μF
C512 176-1011-00 100pF CH
C513 178-1042-78 0.1μF
C514 178-1042-78 0.1μF
C515 178-1042-78 0.1μF
C517 178-1042-78 0.1μF
C518 173-3931-10 0.039μF J
C519 173-3931-10 0.039μF J
C521 173-1231-10 0.012μF J
C522 173-1231-10 0.012μF J
C523 183-2263-31 16V22μF
C551 183-3353-61 50V3.3μF
C552 176-1011-00 100pF CH
C553 178-1042-78 0.1μF
C554 178-1042-78 0.1μF
C558 173-3931-10 0.039μF J
C559 173-3931-10 0.039μF J
C561 173-1231-10 0.012μF J
C562 173-1231-10 0.012μF J
C563 183-2263-31 16V22μF
C564 183-1063-31 16V10μF
C565 183-1063-31 16V10μF
C592 183-2263-11 6.3V22μF
C593 183-2263-11 6.3V22μF
C600 178-4732-78 0.047μF
C601 178-2232-78 0.022μF
C602 176-1011-00 100pF CH
C900 042-0416-02 10V10μF TAN
C901 178-1042-78 0.1μF
C902 178-1042-78 0.1μF
C903 178-4732-78 0.047μF
C904 178-1032-78 0.01μF
C905 178-1032-78 0.01μF
C906 176-1011-00 100pF CH
C907 178-3332-78 0.033μF
C908 178-1042-78 0.1μF
C909 178-1042-78 0.1μF
C910 178-1042-78 0.1μF
C912 042-0403-00 6.3V22μF TAN
C913 178-1042-78 0.1μF
C914 042-0423-00 10V3.3μF
C915 183-2263-31 16V22μF
C916 183-1073-12 6.3V100μF
C917 178-1042-78 0.1μF
C918 042-0423-00 10V3.3μF
C919 178-1042-78 0.1μF
C920 042-0423-00 10V3.3μF
C921 183-4763-11 6.3V47μF
C922 042-0423-00 10V3.3μF
C924 173-1021-11 1000pF J
C925 178-1042-78 0.1μF
C926 176-2211-00 220pF CH
C927 043-0264-06 270pF
C928 178-1042-78 0.1μF
C929 042-0423-00 10V3.3μF
C930 183-2263-31 16V22μF
C931 183-1073-12 6.3V100μF
C932 178-1042-78 0.1μF
C933 042-0423-00 10V3.3μF
C934 178-1042-78 0.1μF
C935 042-0423-00 10V3.3μF
C936 183-4763-11 6.3V47μF
C937 042-0423-00 10V3.3μF
C939 173-1021-11 1000pF J
C940 178-1042-78 0.1μF
C941 176-2211-00 220pF CH
C942 043-0264-06 270pF
C943 178-1042-78 0.1μF
C944 178-1042-78 0.1μF
C945 178-1042-78 0.1μF
C946 183-4763-11 6.3V47μF
C947 183-4763-11 6.3V47μF
C948 042-0416-02 10V10μF TAN
C949 042-0416-02 10V10μF TAN
C950 178-1042-78 0.1μF
C951 178-1222-78 1200pF
C952 178-1042-78 0.1μF
C953 178-1032-78 0.01μF
C954 176-1011-00 100pF CH
C956 178-1032-78 0.01μF
D5 001-0557-00 HVR187
D6 001-0557-00 HVR187
D8 001-0503-47 HZS9B3L
D200 001-0377-32 MA4056M
D201 001-0377-45 MA4082H
D204 001-0589-00 1SS145
D207 001-0516-00 MA111
D208 001-0330-00 1SS119
D209 001-0377-15 MA4033H
D210 001-0423-31 MA4180
D211 001-0466-00 S5688B
D213 001-0516-00 MA111
D310 001-0466-00 S5688B
D311 001-0516-00 MA111
D312 001-0516-00 MA111
D313 001-0516-00 MA111
D314 001-0516-00 MA111
D315 001-0516-00 MA111
D316 001-0516-00 MA111
D317 001-0528-43 MA8082-L
D600 001-0516-00 MA111
D603 001-0516-00 MA111
D604 001-0516-00 MA111
