Clarion DRX9255EXL Service Manual

- 8 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D605 001-0516-00 MA111
D900 001-0516-00 MA111
D901 001-0516-00 MA111
D902 001-0516-00 MA111
D903 001-0516-00 MA111
D905 001-0377-32 MA4056M
D906 001-0377-32 MA4056M
D908 001-0516-00 MA111
D910 001-0516-00 MA111
IC1 051-1282-00 TA7372P
IC2 051-1717-05 LC7219M
IC200 051-3201-00 AN77L06
IC300 051-3013-00 M5203AFP
IC302 051-3013-00 M5203AFP
IC450 051-3012-00 OP275GS
IC470 051-3012-00 OP275GS
IC510 051-3010-00 NJM4580E
IC550 051-3010-00 NJM4580E
IC561 051-1904-00 μPC4570G2
IC600 052-3327-01 μPD78058FGC-
029-3B9
IC602 051-7400-06 HD74LS07FP
IC603 051-0869-05 MB3771PF(-G)
IC900 051-6317-05 CS8412CS
IC901 051-1443-06 TC7WU04F
IC902 051-0857-35 MC74HC00AF
IC903 051-6316-00 SM5845AF
IC904 051-6306-08 PCM1702U
IC905 051-1787-00 OPA2604AU
IC906 051-6306-08 PCM1702U
IC907 051-1787-00 OPA2604AU
J200 074-0884-00 OUTLET SOCKET
J201 074-1106-10 10P
J300 074-1106-10 10P
J500 074-1106-08 8P
J600 074-0986-26 26P
L1 010-4008-00 76μH
L2 010-2230-64 2.2μH
L3 010-2230-88 220μH
L5 010-2230-64 2.2μH
L200 010-2199-66 2.2μH J
L401 010-2198-56 2.2μH
L402 010-2198-56 2.2μH
L900 010-2199-74 10μH J
L901 010-2230-80 47μH
P200 076-0515-10 10P
P400 076-0515-10 10P
P401 076-0313-06 6P
P500 076-0515-08 8P
P601 076-0515-20 20P
P602 076-0313-02 2P
P900 075-0305-01 OPT-DIGITAL
Q1 102-2712-00 2SC2712
Q2 125-2004-03 RN1403
Q3 102-2712-51 2SC2712G,L
Q4 100-1298-00 2SA1298
Q5 100-1298-00 2SA1298
Q6 102-2712-51 2SC2712G,L
Q7 102-2712-51 2SC2712G,L
Q8 103-1802-60 2SD1802FA-R.S.T
Q200 103-2118-00 2SD2118
Q201 100-1162-00 2SA1162
Q203 103-2012-00 2SD2012
Q204 100-1162-00 2SA1162
Q205 125-2004-06 RN1406
Q209 101-1237-00 2SB1237
Q210 102-2712-00 2SC2712
Q211 101-1237-00 2SB1237
Q212 101-1237-00 2SB1237
Q213 125-2004-06 RN1406
Q216 101-1274-00 2SB1274
Q217 103-1858-00 2SD1858
Q219 100-1162-00 2SA1162
Q220 125-2004-06 RN1406
Q221 102-2712-00 2SC2712
Q222 103-1683-00 2SD1683
Q301 125-2004-02 RN1402
Q303 125-2004-06 RN1406
Q304 125-2004-06 RN1406
Q305 125-2004-03 RN1403
Q306 103-1328-00 2SD1328
Q307 103-1328-00 2SD1328
Q308 125-0002-03 RN2403
Q309 102-2712-00 2SC2712
Q310 100-1162-00 2SA1162
Q450 103-1328-00 2SD1328
Q451 103-1328-00 2SD1328
Q470 103-1328-00 2SD1328
Q471 103-1328-00 2SD1328
Q512 125-0002-03 RN2403
Q513 125-0002-03 RN2403
Q552 125-0002-03 RN2403
Q553 125-0002-03 RN2403
Q600 125-2004-02 RN1402
Q601 125-2004-02 RN1402
Q602 102-2712-00 2SC2712
Q603 100-1162-00 2SA1162
Q604 125-2004-02 RN1402
Q605 102-2712-00 2SC2712
Q606 125-2004-02 RN1402
Q902 125-2004-03 RN1403
Q903 125-2004-02 RN1402
Q905 125-2004-03 RN1403
Q906 101-1237-00 2SB1237
Q907 103-1683-00 2SD1683
Q908 101-1143-00 2SB1143
Q909 125-0002-03 RN2403
Q910 125-2004-03 RN1403
Q911 125-2004-03 RN1403
Q912 125-0002-03 RN2403
Q913 125-2004-03 RN1403
Q918 125-2004-03 RN1403
R1 117-5631-10 1/10W 56kΩ
R2 117-6811-10 1/10W 680Ω
R3 117-3331-10 1/10W 33kΩ
R4 117-1821-10 1/10W 1.8kΩ
R5 117-3331-10 1/10W 33kΩ
R6 117-1041-10 1/10W 100kΩ
R7 117-1231-10 1/10W 12kΩ
R8 117-1031-10 1/10W 10kΩ
R9 117-1001-10 1/10W 10Ω
R10 117-1221-10 1/10W 1.2kΩ
R11 117-1221-10 1/10W 1.2kΩ
R12 117-6831-10 1/10W 68kΩ
R13 117-2221-10 1/10W 2.2kΩ
R14 117-1031-10 1/10W 10kΩ
R16 117-1031-10 1/10W 10kΩ
R17 117-1041-10 1/10W 100kΩ
R18 117-1041-10 1/10W 100kΩ
R19 117-2231-10 1/10W 22kΩ
R20 117-2231-10 1/10W 22kΩ
R21 117-2221-10 1/10W 2.2kΩ
R22 117-2221-10 1/10W 2.2kΩ
R23 117-2221-10 1/10W 2.2kΩ
R24 117-1221-10 1/10W 1.2kΩ
R25 117-1221-10 1/10W 1.2kΩ
R26 117-1031-10 1/10W 10kΩ
R27 117-1031-10 1/10W 10kΩ
R28 117-1021-10 1/10W 1kΩ
R29 117-2221-10 1/10W 2.2kΩ
R30 117-4721-10 1/10W 4.7kΩ
R40 111-5611-91 1/4WS 560Ω
R200 111-1511-91 1/4WS 150Ω
R201 117-1831-10 1/10W 18kΩ
R202 117-1031-10 1/10W 10kΩ
R203 111-3311-91 1/4WS 330Ω
R204 117-4721-10 1/10W 4.7kΩ
R205 117-1031-10 1/10W 10kΩ
R212 111-1221-91 1/4WS 1.2kΩ
R213 117-1031-10 1/10W 10kΩ
R214 117-4721-10 1/10W 4.7kΩ
R215 111-3311-91 1/4WS 330Ω
R216 111-1031-91 1/4WS 10kΩ
R217 117-1031-10 1/10W 10kΩ
R218 111-1221-91 1/4WS 1.2kΩ
R221 111-1801-91 1/4WS 18Ω
R222 117-5621-10 1/10W 5.6kΩ
R223 111-1001-91 1/4WS 10Ω
R226 117-3311-10 1/10W 330Ω
R227 117-2231-10 1/10W 22kΩ
R228 117-1031-10 1/10W 10kΩ
R229 117-4721-10 1/10W 4.7kΩ
R230 117-4721-10 1/10W 4.7kΩ
R231 117-2231-10 1/10W 22kΩ
R233 117-1511-10 1/10W 150Ω
R235 111-2721-91 1/4WS 2.7kΩ
R236 111-3311-91 1/4WS 330Ω
R300 117-5631-10 1/10W 56kΩ
R301 117-1031-10 1/10W 10kΩ
R302 117-6821-10 1/10W 6.8kΩ
R303 117-1531-10 1/10W 15kΩ
R304 117-5631-10 1/10W 56kΩ
R305 117-2231-10 1/10W 22kΩ
R308 117-8221-10 1/10W 8.2kΩ
R309 117-4731-10 1/10W 47kΩ
R320 117-5631-10 1/10W 56kΩ
R321 117-1031-10 1/10W 10kΩ
R322 117-6821-10 1/10W 6.8kΩ
R323 117-1531-10 1/10W 15kΩ
R324 117-4731-10 1/10W 47kΩ
R325 117-5631-10 1/10W 56kΩ
R326 117-8221-10 1/10W 8.2kΩ
R327 117-2231-10 1/10W 22kΩ
R349 117-1021-10 1/10W 1kΩ
R350 117-3321-10 1/10W 3.3kΩ
R351 117-8211-10 1/10W 820Ω
R353 117-8231-10 1/10W 82kΩ
R354 117-3311-10 1/10W 330Ω
R355 117-1021-10 1/10W 1kΩ
R356 117-3311-10 1/10W 330Ω
R357 117-1021-10 1/10W 1kΩ
R358 117-1021-10 1/10W 1kΩ
R359 117-5621-10 1/10W 5.6kΩ
R365 117-4731-10 1/10W 47kΩ
R366 117-4721-10 1/10W 4.7kΩ
R367 117-2221-10 1/10W 2.2kΩ
R368 117-1031-10 1/10W 10kΩ
R369 117-1031-10 1/10W 10kΩ
R370 117-8211-10 1/10W 820Ω
R450 117-5631-10 1/10W 56kΩ
R451 032-0106-80 1/10W 5.1kΩ±0.5%
R452 032-0106-80 1/10W 5.1kΩ±0.5%
R453 032-0144-53 1/10W 10kΩ
R454 117-1011-10 1/10W 100Ω
R455 117-1011-10 1/10W 100Ω
R456 032-0144-53 1/10W 10kΩ
R457 117-2731-10 1/10W 27kΩ
R458 117-2731-10 1/10W 27kΩ
R459 117-3311-10 1/10W 330Ω
R460 117-3311-10 1/10W 330Ω
R461 117-5631-10 1/10W 56kΩ
R470 117-5631-10 1/10W 56kΩ
R471 032-0106-80 1/10W 5.1kΩ±0.5%
R472 032-0106-80 1/10W 5.1kΩ±0.5%
R473 032-0144-53 1/10W 10kΩ
R474 117-1011-10 1/10W 100Ω
R475 117-1011-10 1/10W 100Ω
R476 032-0144-53 1/10W 10kΩ
R477 117-2731-10 1/10W 27kΩ
R478 117-2731-10 1/10W 27kΩ
R479 117-3311-10 1/10W 330Ω
R480 117-3311-10 1/10W 330Ω
R481 117-5631-10 1/10W 56kΩ
R513 032-0144-50 1/10W 1kΩ
R514 117-1041-10 1/10W 100kΩ
R516 117-5631-10 1/10W 56kΩ
R517 117-6821-10 1/10W 6.8kΩ
R518 117-6821-10 1/10W 6.8kΩ
R519 032-0144-51 1/10W 4.7kΩ
R520 032-0144-51 1/10W 4.7kΩ
R522 117-1051-10 1/10W 1MΩ
R523 117-1051-10 1/10W 1MΩ
R524 117-1021-10 1/10W 1kΩ
R525 117-1021-10 1/10W 1kΩ
