Clarion DXZ635MP User Manual

2 DXZ635MP
280-7900-00
1. FEATURES
• MP3 and WMA File Playable with ID3-TAG and WMA-TAG Display
• DUAL ZONE Control with Dedicated RCA Line Level Outputs
• 1-Bit D/A Converters and 8-Times Oversampling Digital Filter
• Z-ENHANCER PLUS for Sound Creation with 4 Adjustment Modes (2-Band P.EQ)
• MAGNA BASS EX for Dynamic Bass Tuning, Volume Level Dependent
• DIN Chassis with Detachable Control Aluminum Face with Blue Negative LC Display
• Screen Saver with User Programmable MESSAGE INFORMATION
• CeNET with Balanced Audio Line Transmission and Dynamic Noise Canceling
280-7900-00
English
Contents
1. FEATURES ...................................................................................................................................... 2
2. PRECAUTIONS ............................................................................................................................... 3
Handling Compact Discs ................................................................................................................. 4
3. CONTROLS ..................................................................................................................................... 5
4. NOMENCLATURE .......................................................................................................................... 6
Names of the Buttons and their Functions ...................................................................................... 6
Major button operations when external equipment is connected to this unit ................................... 7
Display Items ................................................................................................................................... 8
LCD Screen ..................................................................................................................................... 8
5. DCP ................................................................................................................................................. 9
6. REMOTE CONTROL ..................................................................................................................... 10
Inserting the Batteries ................................................................................................................... 10
Functions of Remote Control Unit Buttons .................................................................................... 11
7. OPERATIONS ............................................................................................................................... 12
Basic Operations ........................................................................................................................... 12
Radio Operations ........................................................................................................................... 14
CD/MP3/WMA Operations ............................................................................................................. 16
Operations Common to Each Mode .............................................................................................. 20
8. OPERATIONS OF ACCESSORIES .............................................................................................. 23
CD/MD Changer Operations.......................................................................................................... 23
TV Operations ................................................................................................................................ 25
9. IN CASE OF DIFFICULTY ............................................................................................................ 27
10. ERROR DISPLAYS ....................................................................................................................... 28
11. SPECIFICATIONS ......................................................................................................................... 30
Thank you for purchasing this Clarion product.
∗ Please read this owner’s manual in its entirety before operating this equipment.
∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
∗ Check the contents of the enclosed warranty card and keep it carefully with this manual.
∗ This manual includes the operating procedures of the CD changer, MD changer and TV tuner con-
nected via the CeNET cable. The CD changer, MD changer and TV tuner have their own manuals,
but no explanations for operating them are described.
Sintonizador de FM
Gama de frecuencias:
87,9 a 107,9 MHz
Sensibilidad útil:
9 dBf
Sensibilidad a 50 dB de silenciamiento:
15 dBf
Selectividad de canal alternativo:
70 dB
Separación entre canales (1 kHz):
35 dB
Respuesta en frecuencia (±3 dB):
30 Hz a 15 kHz
Sintonizador de AM
Gama de frecuencias:
530 a 1710 kHz
Sensibilidad útil:
25 µV
Reproductor de discos compactos
Sistema:
Sistema audiodigital de discos compactos
Discos utilizables:
Discos compactos
Respuesta en frecuencia (±1 dB):
5 Hz a 20 kHz
Relación señal-ruido (1 kHz):
100 dBA
Gama dinámica (1 kHz):
95 dB
Distorsión armónica:
0,01%
Separación entre canales (1 kHz):
85 dB
Audio
Salida máxima de potencia:
208 W (52 W ✕ 4 canales)
Salida media continua de potencia:
17 W ✕ 4, con 4 Ω, de 20 Hz a 20 kHz, 1% de
distorsión armónica total
Acción de control de graves
(50 Hz/80 Hz/120 Hz):
+16 dB, -12dB
Acción de control de agudos (8 kHz/12 kHz):
±12 dB
Nivel de salida de línea (CD a 1 kHz):
1,8 V
Generales
Tensión de alimentación:
14,4 V CC (permisible de 10,8 a 15,6 V),
negativo a masa
Consumo de corriente:
Menos de 15 A, 3 A
Impedancia de los altavoces:
4 Ω (permisible de 4 a 8 Ω)
Peso / Unidad fuente:
2,86 lb. (1,3 kg)
Peso / Controlador remoto:
1 oz. (30 g) (incluyendo la pila)
Dimensiones / Unidad fuente:
7" (An) ✕ 2" (Al) ✕ 6-1/8" (Prf)
[178 (An) ✕ 50 (Al) ✕ 155 (Prf) mm]
Dimensiones / Controlador remoto:
1-3/4" (An) ✕ 4-5/16" (Al) ✕ 1-1/8" (Prf)
[44 (An) ✕ 110 (Al) ✕ 27 (Prf) mm]
11. ESPECIFICACIONES
Nota:
• Las especificaciones y el diseño están sujetos a cambio sin previo aviso por motivo de mejoras.
DXZ635MP 89
Español

Clarion DXZ635MP Specifications

FM Tuner

frequency range	87.9 MHz to 107.9 MHz
usable sensitivity	9 dBf
50dB quieting sensitivity	15 dBf
alternate channel selectivity	70 dB
stereo separation (1 kHz)	35 dB
frequency response (±3 dB)	30 Hz to 15 kHz

AM Tuner

frequency range	530 kHz to 1710 kHz
usable sensitivity	25 µV

CD Player

system	Compact disc digital audio system
usable discs	Compact disc
frequency response (±1 dB)	5 Hz to 20 kHz
signal to noise ratio (1 kHz)	100 dBA
dynamic range (1 kHz)	95 dB
harmonic distortion	0.01%
channel separation (1 kHz)	85 dB

Audio

maximum power output	208 W (52 W ✕ 4 ch)
continuous average power output	17 W ✕ 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
bass control action (50 Hz/80 Hz/120 Hz)	+16 dB, -12dB
treble control action (8 kHz/12 kHz)	±12 dB
line output level (CD 1 kHz)	1.8 V

General

power supply voltage	14.4 V DC (10.8 to 15.6 V allowable), negative ground
current consumption	Less than 15 A, 3A
speaker impedance	4 Ω (4 Ω to 8 Ω allowable)
weight / source unit	2.86 lb. (1.3 kg)
weight / remote control unit	1 oz. (30 g) (including battery)
dimensions / source unit	7" (Width) ✕ 2" (Height) ✕ 6-1/8" (Depth) [178 (W) ✕ 50 (H) ✕ 155 (D) mm]
dimensions / remote control unit	1-3/4" (Width) ✕ 4-5/16" (Height) ✕ 1-1/8" (Depth) [44 (W) ✕ 110 (H) ✕ 27 (D) mm]
