Clarion DXZ635MP User Manual

DXZ635MP 13
English
“Z+ OFF” ➜ “BASS BOOST” ➜ “IMPACT” ➜
“EXCITE” ➜ “CUSTOM” ➜ “Z+ OFF” ...
• BASS BOOST : bass emphasized
• IMPACT : bass and treble empha-
sized
• EXCITE : bass and treble empha-
sized mid de-emphasized
• CUSTOM : user custom
• Z+ OFF : no sound effect
Adjusting the Z-Enhancer Plus
1. Press the [Z+] button and select the Z-En-
hancer Plus mode to adjust.
2. Press the [A-M] button and turning the
[ROTARY] knob clockwise adjusts in the +
direction; tuning it counterclockwise adjusts
in the – direction.
● When “B-BOOST 0” selected, you can ad-
just the bass in the range of –3 to 3.
● When “IMPACT 0” selected, you can adjust
the bass and treble in the range of –3 to 3.
● When “EXCITE 0” selected, you can adjust
the bass and treble in the range of –3 to 3.
∗ When Z-Enhancer Plus is selected, press and
hold the [Z+] button for 1 second or longer to
change to the “CUSTOM” mode.
Bass/treble characteristics become flat and
the indication “Z+FLAT” is shown in the dis-
play.
Adjusting the tone
Press the [A-M] button and select the item to
adjust. Each time you press the [A-M] button,
the item changes as following order:
● When “BASS BOOST” is set
“B-BOOST” ➜ “BAL 0” ➜ “FADER 0” ➜
Last function mode.
● When “IMPACT” is set
“IMPACT” ➜ “BAL 0” ➜ “FADER 0” ➜ Last
function mode.
● When “EXCITE” is set
“EXCITE” ➜ “BAL 0” ➜ “FADER 0” ➜ Last
function mode.
● When “CUSTOM” is set
“BASS” ➜ “TREBLE” ➜ “BAL 0” ➜ “FADER
0” ➜ Last function mode.
● When “Z+ OFF” is set
“BAL 0” ➜ “FADER 0” ➜ Last function
mode.
Adjusting the bass (Gain,
Frequency, Q-curve)
This adjustment can be performed when the Z-
Enhancer Plus is set to “CUSTOM”.
1.
Press the [A-M] button and select “BASS”.
2. Turning the [ROTARY] knob clockwise em-
phasizes the bass; turning it counterclock-
wise attenuates the bass.
∗ The factory default setting is “B
ÅÅ
ÅÅ
Å
GAIN 0
ÎÎ
ÎÎ
Î
”.
(Adjustment range: –6 to +8)
3. Press the [d] or [a] button to select
“B
ÅÅ
ÅÅ
Å
FREQ 50
ÎÎ
ÎÎ
Î
”.
Turninng the [ROTARY] knob clockwise or
counterclockwise to select the frequency.
∗ The factory default setting is “B
ÅÅ
ÅÅ
Å
FREQ 50
ÎÎ
ÎÎ
Î
”.
(Adjustment 50/80/120 Hz)
4. Press the [d] or [a] button to select “B
ÅÅ
ÅÅ
Å
Q 1
ÎÎ
ÎÎ
Î
”.
Turninng the [ROTARY] knob clockwise or
counterclockwise to select the Q-curve.
∗ The factory default setting is “B
ÅÅ
ÅÅ
Å
Q 1
ÎÎ
ÎÎ
Î
”.
(Adjustment 1/1.25/1.5/2)
5. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the treble (Gain,
Frequency)
This adjustment can be performed when the Z-
Enhancer Plus is set to “CUSTOM”.
1.
Press the [A-M] button and select “TREBLE”.
2. Turning the [ROTARY] knob clockwise em-
phasizes the treble; turning it counterclock-
wise attenuates the treble.
∗ The factory default setting is “T
ÅÅ
ÅÅ
Å
GAIN 0
ÎÎ
ÎÎ
Î
”.
(Adjustment range: –6 to +6)
3. Press the [d] or [a] button to select
“T
ÅÅ
ÅÅ
Å
FREQ 12k
ÎÎ
ÎÎ
Î
”.
Turninng the [ROTARY] knob clockwise or
counterclockwise to select the frequency.
∗ The factory default setting is “T
ÅÅ
ÅÅ
Å
FREQ 12k
ÎÎ
ÎÎ
Î
”.
(Adjustment 8 kHz/12 kHz)
4. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Basic Operations

Clarion DXZ635MP Specifications

FM Tuner

frequency range	87.9 MHz to 107.9 MHz
usable sensitivity	9 dBf
50dB quieting sensitivity	15 dBf
alternate channel selectivity	70 dB
stereo separation (1 kHz)	35 dB
frequency response (±3 dB)	30 Hz to 15 kHz

AM Tuner

frequency range	530 kHz to 1710 kHz
usable sensitivity	25 µV

CD Player

system	Compact disc digital audio system
usable discs	Compact disc
frequency response (±1 dB)	5 Hz to 20 kHz
signal to noise ratio (1 kHz)	100 dBA
dynamic range (1 kHz)	95 dB
harmonic distortion	0.01%
channel separation (1 kHz)	85 dB

Audio

maximum power output	208 W (52 W ✕ 4 ch)
continuous average power output	17 W ✕ 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
bass control action (50 Hz/80 Hz/120 Hz)	+16 dB, -12dB
treble control action (8 kHz/12 kHz)	±12 dB
line output level (CD 1 kHz)	1.8 V

General

power supply voltage	14.4 V DC (10.8 to 15.6 V allowable), negative ground
current consumption	Less than 15 A, 3A
speaker impedance	4 Ω (4 Ω to 8 Ω allowable)
weight / source unit	2.86 lb. (1.3 kg)
weight / remote control unit	1 oz. (30 g) (including battery)
dimensions / source unit	7" (Width) ✕ 2" (Height) ✕ 6-1/8" (Depth) [178 (W) ✕ 50 (H) ✕ 155 (D) mm]
dimensions / remote control unit	1-3/4" (Width) ✕ 4-5/16" (Height) ✕ 1-1/8" (Depth) [44 (W) ✕ 110 (H) ✕ 27 (D) mm]
