Clarion DXZ785USB User Manual

Basic Operations
English
20 DXZ785USB
● Setting the X-OVER
This function allows you to adjust the speaker
setting such as cutoff frequencies or slope
matched to the speakers you are using.
(Crossover).
2-1. Select “X-OVER”.
3-1. Press the [ ] button.
3-2. Push the [SEEK PANEL] leftward or
rightward and select from:
3-3. Push the [P.CH] button upward or
downward to adjust the “HPF”, “HPF
SLOPE”, “PHASE”, “LPF” and “LPF
SLOPE”.
● HIGH
● MID
● SUB-W (3WAY)/REAR (2WAY)
3-4. Press the [ ] button to store into
memory.
• HIGH
• HPF
• HPF SLOPE
• PHASE
• MID
• LPF
• LPF SLOPE
• HPF
• HPF SLOPE
• PHASE
• SUB-W
• LPF
• LPF SLOPE
•HPF
•HPF SLOPE
• PHASE
• HIGH
3WAY mode
(High pass filter)
(HPF slope)
(Phase)
(Front speaker (high))
(Front speaker (mid))
(Subwoofer)
(Low pass filter)
(LPF slope)
• HIGH
• HPF
• HPF SLOPE
• PHASE
• MID
• LPF
• LPF SLOPE
• HPF
• HPF SLOPE
2WAY mode
• PHASE
• REAR
• LPF
• LPF SLOPE
• HPF
• HPF SLOPE
• PHASE
• HIGH
(Front speaker (high))
(Front speaker (mid))
(Rear speaker)
(High pass filter)
(HPF slope)
(Phase)
(Low pass filter)
(LPF slope)
Items Adjustable
range
Initial value
HPF THRGH
(through), 25
Hz to 20 kHz
2 kHz
HPF SLOPE –6 dB, –12 dB,
–18 dB
–12 dB
PHASE NOR (normal),
REV (reverse)
NOR (normal)
Items Adjustable
range
Initial value
LPF 630 Hz to 10
kHz, THRGH
(through)
2 kHz
LPF SLOPE –6 dB, –12 dB,
–18 dB
–12 dB
HPF THRGH
(through), 25
Hz to 10 kHz
THRGH
(through)
HPF SLOPE –6 dB, –12 dB,
–18 dB
–12 dB
PHASE NOR (normal),
REV (reverse)
NOR (normal)
Items Adjustable
range
Initial value
LPF 25 Hz to 10
kHz, THRGH
(through)
80 Hz
LPF SLOPE –6 dB, –12 dB,
–18 dB
–12 dB
HPF THRGH
(through), 16
Hz to 250 Hz
THRGH
(through)
HPF SLOPE –6 dB, –12 dB,
–18 dB
–12 dB
PHASE NOR (normal),
REV (reverse)
NOR (normal)
