- 6 -
PN-2121D
24 286-8153-04 SETPLATE(D-A) 1
286-8153-08 SETPLATE(N-A)
286-8153-05 SETPLATE(I-A)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
System control PWB section
D 519 001-0330-00 1SS119
D 519 001-0352-00 1SS176
D 521 001-0330-00 1SS119
D 521 001-0352-00 1SS176
R 521 111-1021-91 1/4W 1kΩ
Display PWB section
■ PARTS LIST/PP-2121I-A
Main PWB section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C 114 184-4773-22 10V 470μF
R 154 117-4721-10 1/10W 4.7kΩ
R 157 117-4721-10 1/10W 4.7kΩ
R 226 117-5621-10 1/10W 5.6kΩ
R 227 117-5621-10 1/10W 5.6kΩ
R 228 117-2431-15 1/10W 24kΩ
R 229 117-2431-15 1/10W 24kΩ
R 230 117-5621-10 1/10W 5.6kΩ
R 231 117-5621-10 1/10W 5.6kΩ
R 232 117-2431-15 1/10W 24kΩ
R 233 117-2431-15 1/10W 24kΩ
System control PWB section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D 520 001-0330-00 1SS119 D 520 001-0352-00 1SS176 D 521 DELETE
Display PWB section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
PL 701 017-0433-05 14V 40mA
PL 702 017-0433-05 14V 40mA
PL 703 017-0433-05 14V 40mA
PL 704 017-0433-05 14V 40mA
PL 705 017-0433-05 14V 40mA
PL 706 017-0433-05 14V 40mA
PL 707 017-0433-05 14V 40mA
PL 708 017-0433-05 14V 40mA
PL 709 017-0433-05 14V 40mA
■ EXPLODED VIEW・PARTS LIST
Escutcheon section
NO. PART NO. DESCRIPTION Q'TY
NO. PART NO. DESCRIPTION Q'TY
Note)Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
1 940-7759-00 ESCUTCHEON ASS'Y(D-A,I-A) 1
940-7765-00 ESCUTCHEON ASS'Y(N-A)
6 017-0433-02 PILOT LAMP(D-A,N-A) 9
017-0433-05 PILOT LAMP(I-A)
23 320-0512-05 DUSTPROOF COVER(D-A) 1
320-0512-04 DUSTPROOF COVER(N-A)
320-0512-03 DUSTPROOF COVER(I-A)
Main section
NO. PART NO. DESCRIPTION Q'TY
REF No. PART No. DESCRIPTION
S 717 013-6300-00
To Next Page
