Clarion PP-3000M-A User Manual

PN-3000P
PP-3000M
- 12 -
IC107 051-7255-08 SN74AHC1G66
HDCKR
IC204 051-3340-00 LD1085P
IC205 051-3516-90 S-1132B33-U5T1G
IC301 ----------- SAF7730HV/N317
IC402 ----------- M30876FJBGP
IC404 051-5417-08 S-80927CNMC-G8X
IC406 051-9425-80 S-24CS64A0I-J8T1G
IC501 051-3019-90 NJM2060V
IC502 051-3518-90 NJM2846DL3-33-
TE1
IC503 051-2042-00 TA8275H
IC504 051-3396-90 NJM2386ADL3-33-
TE1
IC505 051-3517-90 LT3481EMSE
#TRPBF
IC506 051-5441-08 BD4828G-TR
J201 074-1302-12 TH12P-SOCKET
J202 074-1237-69 19PIN
J204 074-1013-00 12P
J502 074-4009-20 SOCKET(20P)
L105 010-2003-04 30uH
L106 010-3104-54 600 ohm/100MHz
L107 010-3104-54 600 ohm/100MHz
L108 010-2198-50 0.15uH
L301 010-3104-54 600 ohm/100MHz
L302 010-3104-54 600 ohm/100MHz
L303 010-3104-54 600 ohm/100MHz
L304 010-3104-54 600 ohm/100MHz
L305 010-3104-54 600 ohm/100MHz
L306 010-3104-54 600 ohm/100MHz
L307 010-3104-54 600 ohm/100MHz
L308 010-3104-54 600 ohm/100MHz
L309 010-3104-54 600 ohm/100MHz
L310 010-3104-54 600 ohm/100MHz
L311 010-3104-54 600 ohm/100MHz
L312 010-3104-54 600 ohm/100MHz
L313 010-3104-54 600 ohm/100MHz
L402 010-3406-54 2.2uH J
L501 010-3104-54 600 ohm/100MHz
L503 010-3414-90 6.8uH
P101 076-3011-66 16P
P401 076-0478-59 PLUG (9P)
P402 076-3011-72 22P
Q101 198-3018-00 2SK3018
Q102 198-3018-00 2SK3018
Q104 125-9017-92 UMD3N-TR
Q105 125-2027-91 DTC114EUA
Q106 125-2027-91 DTC114EUA
Q107 125-2027-91 DTC114EUA
Q108 125-2027-91 DTC114EUA
Q109 192-5886-00 2SC5886
Q110 125-2027-90 DTC143EU
(PN-3000P)
Q111 190-2060-00 2SA2060
(PN-3000P)
Q112 125-9017-92 UMD3N-TR
Q201 192-4081-00 2SC4081
Q204 125-9017-92 UMD3N-TR
Q206 198-3018-00 2SK3018
Q207 198-3018-00 2SK3018
Q219 125-2027-90 DTC143EU
Q220 191-1197-50 2SB1197K Q,R
Q222 125-9017-92 UMD3N-TR
Q301 125-7007-90 Si5441BDC-TI-E3
Q302 125-2027-91 DTC114EUA
Q303 125-2027-91 DTC114EUA
Q304 125-2027-91 DTC114EUA
Q305 125-2027-91 DTC114EUA
Q306 125-2027-91 DTC114EUA
Q307 125-2027-91 DTC114EUA
Q308 125-2027-91 DTC114EUA
Q401 125-2027-91 DTC114EUA
Q402 125-0021-91 DTA114EUA
Q403 191-0709-00 2SB709A Q,R,S
Q404 192-2712-00 2SC2712
Q405 125-2027-91 DTC114EUA
Q406 125-0006-90 UN2110
Q503 125-2027-91 DTC114EUA
Q504 191-1197-50 2SB1197K Q,R
Q506 125-2027-91 DTC114EUA
Q507 191-1197-50 2SB1197K Q,R
Q509 193-2118-00 2SD2118F5 Q,R,S
Q512 125-2027-91 DTC114EUA
Q515 193-1664-00 2SD1664 P,Q,R
Q516 192-4116-51 2SC4116 G,L
Q517 191-1204-61 2SB1204 R,S,T
Q518 125-2027-91 DTC114EUA
Q519 191-1197-50 2SB1197K Q,R
Q520 192-4116-00 2SC4116
Q521 192-4081-00 2SC4081
Q522 125-2027-91 DTC114EUA
Q523 192-4081-00 2SC4081
R103 119-3321-15 1/10W 3.3k ohm
R106 119-0000-05 1/10W 0 ohm JW
R109 119-3321-15 1/10W 3.3k ohm
R111 119-3321-15 1/10W 3.3k ohm
R112 119-0000-05 1/10W 0 ohm JW
R113 119-3321-15 1/10W 3.3k ohm
R116 119-2741-15 1/10W 270k ohm
R117 119-3331-15 1/10W 33k ohm
R118 119-3931-15 1/10W 39k ohm
R121 119-3931-15 1/10W 39k ohm
R122 119-1031-15 1/10W 10k ohm
R123 119-1031-15 1/10W 10k ohm
R124 119-3931-15 1/10W 39k ohm
R125 119-1031-15 1/10W 10k ohm
R126 119-1011-15 1/10W 100 ohm
R127 119-4731-15 1/10W 47k ohm
R128 119-4731-15 1/10W 47k ohm
R129 119-4731-15 1/10W 47k ohm
R130 119-8221-15 1/10W 8.2k ohm
R131 119-1011-15 1/10W 100 ohm
R132 119-1011-15 1/10W 100 ohm
R134 119-1031-15 1/10W 10k ohm
R135 119-2231-15 1/10W 22k ohm
R136 116-6891-15 1/4W 6.8 ohm
R138 119-1031-15 1/10W 10k ohm
R139 119-1041-15 1/10W 100k ohm
R140 119-1001-15 1/10W 10 ohm
R141 119-1031-15 1/10W 10k ohm
R143 119-2231-15 1/10W 22k ohm
R144 119-2231-15 1/10W 22k ohm
R145 119-1001-15 1/10W 10 ohm
R146 119-1031-15 1/10W 10k ohm
R148 116-1091-15 1/4W 1 ohm
(PN-3000P)
R149 116-1221-15 1/4W 1.2k ohm
(PN-3000P)
R150 116-3911-15 1/4W 390 ohm
R151 119-1031-15 1/10W 10k ohm
(PN-3000P)
R153 119-1041-15 1/10W 100k ohm
R162 119-0000-05 1/10W 0 ohm JW
R165 119-1031-15 1/10W 10k ohm
R166 119-1031-15 1/10W 10k ohm
R167 119-1031-15 1/10W 10k ohm
R168 119-1031-15 1/10W 10k ohm
R169 119-1031-15 1/10W 10k ohm
R170 119-1031-15 1/10W 10k ohm
R171 119-0000-05 1/10W 0 ohm JW
R172 119-0000-05 1/10W 0 ohm JW
R173 119-1531-15 1/10W 15k ohm
R174 119-2231-15 1/10W 22k ohm
R175 119-1021-15 1/10W 1k ohm
R176 119-3931-15 1/10W 39k ohm
R177 119-6821-15 1/10W 6.8k ohm
R207 119-3011-15 1/10W 300 ohm
R208 119-3011-15 1/10W 300 ohm
R210 119-1021-15 1/10W 1k ohm
R212 119-3331-15 1/10W 33k ohm
R215 119-4731-15 1/10W 47k ohm
R220 119-1041-15 1/10W 100k ohm
R224 119-4721-15 1/10W 4.7k ohm
R227 119-4721-15 1/10W 4.7k ohm
R229 119-4721-15 1/10W 4.7k ohm
R233 119-4721-15 1/10W 4.7k ohm
R248 116-2201-15 1/4W 22 ohm
R249 032-0140-98 1/10W 330 ohm F
R250 116-1221-15 1/4W 1.2k ohm
R251 032-0140-93 1/10W 2k ohm F
R252 119-1031-15 1/10W 10k ohm
R266 119-0000-05 1/10W 0 ohm JW
R301 119-1031-15 1/10W 10k ohm
R302 119-1031-15 1/10W 10k ohm
R303 119-2201-15 1/10W 22 ohm
R304 032-0140-80 1/10W 18k ohm F
R305 032-0140-80 1/10W 18k ohm F
R306 032-0140-80 1/10W 18k ohm F
R307 032-0140-80 1/10W 18k ohm F
R314 119-1011-15 1/10W 100 ohm
R315 119-1031-15 1/10W 10k ohm
R316 119-1021-15 1/10W 1k ohm
R317 119-1031-15 1/10W 10k ohm
R318 119-3921-15 1/10W 3.9k ohm
R319 119-1031-15 1/10W 10k ohm
R320 119-3921-15 1/10W 3.9k ohm
R321 119-1031-15 1/10W 10k ohm
R322 119-0000-05 1/10W 0 ohm JW
R323 119-1031-15 1/10W 10k ohm
R324 119-1041-15 1/10W 100k ohm
R325 119-1041-15 1/10W 100k ohm
R326 119-1001-15 1/10W 10 ohm
R327 119-3921-15 1/10W 3.9k ohm
R328 119-0000-05 1/10W 0 ohm JW
R329 119-1021-15 1/10W 1k ohm
R330 119-3921-15 1/10W 3.9k ohm
R331 119-0000-05 1/10W 0 ohm JW
R332 032-0140-50 1/10W 10k ohm F
R334 032-0140-50 1/10W 10k ohm F
R336 032-0140-50 1/10W 10k ohm F
R337 032-0140-50 1/10W 10k ohm F
R338 032-0140-50 1/10W 10k ohm F
R339 032-0140-50 1/10W 10k ohm F
R340 032-0140-50 1/10W 10k ohm F
R341 119-1031-15 1/10W 10k ohm
R342 119-1031-15 1/10W 10k ohm
R343 119-1031-15 1/10W 10k ohm
R344 119-1011-15 1/10W 100 ohm
R345 119-1011-15 1/10W 100 ohm
R346 119-0000-05 1/10W 0 ohm JW
R347 119-0000-05 1/10W 0 ohm JW
R348 119-0000-05 1/10W 0 ohm JW
R349 119-0000-05 1/10W 0 ohm JW
R350 119-1031-15 1/10W 10k ohm
R351 119-0000-05 1/10W 0 ohm JW
R352 119-4731-15 1/10W 47k ohm
R353 119-1021-15 1/10W 1k ohm
R354 119-1021-15 1/10W 1k ohm
R355 119-1021-15 1/10W 1k ohm
R356 119-1021-15 1/10W 1k ohm
R357 119-4731-15 1/10W 47k ohm
R358 119-1001-15 1/10W 10 ohm
R359 119-4731-15 1/10W 47k ohm
R360 119-4731-15 1/10W 47k ohm
R361 119-4731-15 1/10W 47k ohm
R362 119-4731-15 1/10W 47k ohm
R400 119-0000-05 1/10W 0 ohm JW
R401 119-1021-15 1/10W 1k ohm
R402 119-1021-15 1/10W 1k ohm
R403 119-1021-15 1/10W 1k ohm
R404 119-0000-05 1/10W 0 ohm JW
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION

Clarion PP-3000M-A Specifications

General

Brand	Clarion
Model	PP-3000M-A
Category	Car Receiver
Language	English
