PN-3000P
PP-3000M
- 9 -
1 940-8206-20 ES-ASSY (PN-3000P-A) 1
940-8206-21 ES-ASSY (PP-3000M-B)
940-8210-20 ES-ASSY (PP-3000M-A)
2 947-0591-00 KNOB ASSY 1
(PN-3000P-A)(PP-3000M-B)
947-0591-20 KNOB ASSY (PP-3000M-A)
3 347-7959-00 SHADE 1
4 380-5655-20 KNOB 1
5 ----------- SWITCH PWB 1
6 335-7693-00 LCD HOLDER 1
7 335-7801-00 LCD LEFLECTOR 1
8 379-1392-50 INDICATOR (LCD) 1
9 331-4166-00 LCD COVER 1
10 016-7004-00 ROTARY SWITCH 1
11 013-6201-52 TACT SWITCH 15
12 013-6202-52 TACT SWITCH 9
13 074-3013-72 OUTLET SOCKET (22P) 1
14 074-3013-66 OUTLET SOCKET (16P) 1
15 345-8090-00 CUSHION RUBBER 1
16 716-0778-52 WAVE SCREW (2 x 6) 10
17 716-0872-51 PAD SCREW (M1.7 x 5) 2
18 345-5805-01 GASKET 1
19 ----------- MAIN PWB 1
20 074-1237-69 OUTLET SOCKET (19P) 1
21 076-0478-59 PLUG (9P) 1
22 076-3011-72 PLUG (22P) 1
23 076-3011-66 PLUG (16P) 1
24 880-2091M TUNER PACK 1
25 092-2210-00 ANT RECEPT 1
26 074-4009-20 OUTLET SOCKET 1
27 074-1302-12 OUTLET SOCKET 1
28 331-3880-00 TR HOLDER 1
29 313-1967-00 HEAT SINK 1
30 716-1646-50 IT SCREW (M2.6 x 8) 1
31 307-0720-00 REAR PLATE 1
32 073-0762-90 TERMINAL 5
33 778-3006-00 SPECIAL T-SCREW (3 x 6) 4
34 074-1013-00 OUTLET SOCKET 1
35 345-5805-01 GASKET 1
36 311-1914-00 LOWER CASE 1
37 313-2030-00 HEAT SINK 1
38 716-0878-50 SCREW (M2.6 x 5) 5
39 309-0822-00 ES PLATE (6CD) 1
40 929-0390-81 CD MECH MODULE 1
41 331-4092-10 CD MECH BRKT (RH) 1
42 331-4091-10 CD MECH BRKT (LH) 1
43 716-3552-00 SCREW (M2.3 x 2.5) 6
44 816-4024-50 FLAT WIRE 1
45 310-1823-10 UPPER CASE 1
46 735-2614-1B MACHINE SCREW (M2.6 x 14) 2
47 714-2606-8B MACHINE SCREW (M2.6 x 6) 17
48 276-0034-55 SET PLATE (PP-3000M-A) 1
276-0034-56 SET PLATE (PP-3000M-B)
276-0034-58 SET PLATE (PN-3000P-A)
49 060-8062-50 CERAMIC-ANT 1
50 060-8079-90 BLUETOOTH MODULE 1
Note) Some parts depend on each model. The model name is specified in the description.
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
