14
ENGLISH
XC1120 Specifi cations
Frequency Response: <10Hz to 250Hz
4 Ohm Power Output (CEA-2006A) 210W x 1 @ <1.0% THD
2 Ohm Power Output (CEA-2006A) 350W x 1 @ <1.0% THD
Signal to Noise Ratio (CEA-2006A) @ 1W/4 Ohms > -88.7 dBA
THD+N at Max Power 4 Ohms < 0.02%
Effi ciency at Full Power (4 Ohms) 86.3%
Input Sensitivity (RCA Preamp) 110mV to 3.5V
Input Sensitivity (Speaker Level) 1.5V to <20V
Crossover Frequencies 60Hz, 90Hz to 250Hz
Crossover Slope -12dB/Octave LPF
216mm
226mm
57mm
70mm
41mm
