Clarion XC6140 User Manual

3
ENGLISH
FEATURES
The Clarion XC6140 amplier is designed with performance and convenience in mind.
Through the use of state-of-the art signal processing and high speed output devices, this
amplier offers excellent sound quality and dynamics. The XC6140 amplier incorporates
the following features:
• High Speed output devices for dynamic performance
• Pulse Width Modulated MOSFET Power Supply for efcient power delivery
• Remote Turn-On with muting for silent start-up
• Variable Low-Pass Electronic Crossover with -12dB/Octave Slope, 50Hz -500Hz
• Adjustable input level controls with ground loop isolation
• 2-Ohm load stable
• Corrosion resistant power, speaker and RCA connections
• BC2 Remote subwoofer level control
• Speaker level input RCA adapters included
• Circuit Boards with a conformal coating to resist moisture damage
• Low Prole design with corrosion resistant high efciency aluminum heat sink
XC6140 CONNECTIONS AND CONTROLS
1. Two 30A Fuses
2. +12V Constant Power Source
3. Remote Turn-On Connection
4. Ground Connection
5. Channel 1&2 Input RCA Connection
6. Signal Pass Through Connection
7. Channel 1&2 Input Sensitivity Control (Gain)
8. BC2 Remote Level Control Connection Jack
9. Channel 1&2 Crossover Frequency Control
10. Channel 1&2 Infrasonic Filter Frequency Control
11. Channel 1&2 Phase Adjustment Control
12. Bass Boost Frequency Control
13. Power/Protect LED
14. Two Positive Speaker Output Terminals
15. Two Negative Speaker Output Terminals
1 2 23 4 5
14
6 7 8 9 10 11 12
1513
