Pod Symbols and Functions 3-7
Section 3. Operator Compartment and Controls
• Transaxle oil temperature
Indicates that the transaxle oil temperature is
excessive. If the light is on, shut down the truck
and service it. The truck will go into shut down
mode after the light flashes for 30 seconds. (the
buzzer sounds)
• Hydraulic oil filter(optional)
Indicates that the main hydraulic system filter is
dirty, restricting fluid flow. If the light stays on,
change the filter element. Occasional flickering of
the light does not indicate a problem.
• Engine oil pressure
Indicates engine oil pressure is too low. If the light
is on, shut down the truck and service it. The truck
will go into shut down mode after the light flashes
for 30 seconds. (the buzzer sounds)If during
operation, while engine is running, oil pressure
switch closes to ground, the buzzer will sound
immediately. After 5 seconds, the engine will
shutdown. The function that has caused the
shutdown will flash the corresponding icon until
the key is returned to the off position.
• Engine check
When the engine has problem, this LED will be
on.
• Alternator charging status
Indicates that the alternator is not properly
charging the battery. Service is required to correct
the problem.
