Section 1.
General Safety Rules
Grades, Ramp
s, Sl
opes, and lnclin
es
1-1
1
Grades, Ramp
s, Slopes, and lnclines
WARNING
!
Never turn on a grade, either loade
d or unloaded.
Unloaded
Loaded
Forks Upgrade
22
24
