Operation
How To Operate Your Truck
Using the tilt control, tilt the upright
back slightly to raise the fork tips
above the floor.
Raising the forks and tilting them back
prevents the forks from catching on
possible obstructions and reduces the
wear on the fork blades if they strike or
drag on the floor.
Put your foot on the accelerator pedal
and push down smoothly until the
truck is moving at the desired speed.
Be alert for pedestrians, other vehicles
or obstructions in your path of travel.
83M420
84M269
Know Your Truck
Operator's Compartment and Controls
83M432
5.16
12. Ignition Key Switch
13. Water Temperature Indicator
14. Battery Charge Indicator
15. Transmission Oil Temp
Indicator
16. Engine Oil Pressure Indicator
17. Fuel Gauge (Gasoline and
dlesel only)
18. Hourmeter
19. Fasten Seat Belt Light
20. Light Switch (Optional)
21. Accessory Switch (Optional)
22. Glow Plug Switch
4.11
84M414
Diesel Engine Only
