9-4 TMX 12-25
Fill Capacities - Fluid Volumes
Drive Axle (total): 8.0 qt (7.6 L)
Hydraulic Sump Tank: 4.0 gal (15.0 L)
Brake Reservoir: 1.0 pt (0.5 L)
Fluid Specifications
Drive Axle Fluid: SAE 80W-90 (GL-5) or AMOCO 1000
Hydraulic Fluid: AW ISO32 (CLARK MS-68)
Brake Fluid: SAE DOT3 or DOT4
Lubricant Specifications
Axle ends, Wheel bearings:
NLGI Grade No. 1 General Purpose (CLARK MS-9B / MS-107B)
Steering linkage, Upright rails, Rollers, Trunnion bushings, Tilt
cylinder rod ends, brake pedal shaft:
NLGI Grade No. 2 General Purpose (CLARK MS-107C)
Always use genuine CLARK replacement parts.
