9-6 ECX 20-32
Battery Capacity Range
36V Battery
48V Battery
Battery (fully charged): 1.275 SG (specific gravity)
[1.310 Exide Load Hog]
Discharged: 1.140 SG (specific gravity)
Fill Capacities - Fluid Volumes
Drive Axle: 9.5 qt (9.0 L)
Hydraulic Sump Tank: 7.4 gal (28.0 L)
Brake Reservoir: 1.0 pt (0.5 L)
Fluid Specifications
Drive Axle Fluid: SAE 80W-90 (GL-5) or AMOCO 1000
Hydraulic Fluid: AW ISO32 (CLARK MS-68)
Brake Fluid: SAE DOT3 or DOT4
Lubricant Specifications
Axle ends, Wheel bearings:
NLGI Grade No. 1 General Purpose (CLARK MS-9B / MS-107B)
Steering linkage, Upright rails, Rollers, Trunnion bushings, Tilt
cylinder rod ends, brake pedal shaft:
NLGI Grade No. 2 General Purpose (CLARK MS-107C)
Always use genuine CLARK replacement parts.
Battery Compartment Cells Plates
Ah @ 6-hour
Rate
kWh
30.4 in (772 mm) 18 25 900-1320 31.3-45.9
30.4 in (772 mm) 18 27/29 975-1540 33.8-53.5
Battery Compartment Cells Plates
Ah @ 6-hour
Rate
kWh
34.4 in (873 mm) 24 19 675-990 31.4-45.8
34.4 in (873 mm) 24 21 750-1100 35.0-50.9
