9-12 GTX 16-20s
Battery Capacity Range
36V Battery
48V Battery
Battery (fully charged): 1.275 SG (specific gravity)
[1.310 Exide Load Hog]
Discharged: 1.140 SG (specific gravity)
Fill Capacities - Fluid Volumes
Drive Axle (total): 2.1 qt (2.0 L)
Hydraulic Sump Tank: 4.0 gal (15.0 L)
Brake Reservoir: 1.0 pt (0.5 L)
Fluid Specifications
Drive Axle Fluid: Mobil #424
Hydraulic Fluid: AW ISO32 (CLARK MS-68)
Brake Fluid: AW ISO32 (CLARK MS-68)
Lubricant Specifications
Axle ends, Wheel bearings:
NLGI Grade No. 1 General Purpose (CLARK MS-9B / MS-107B)
Steering linkage, Upright rails, Rollers, Trunnion bushings, Tilt
cylinder rod ends, brake pedal shaft:
NLGI Grade No. 2 General Purpose (CLARK MS-107C)
Always use genuine CLARK replacement parts.
Battery Compartment Cells Plates
Ah @ 6-hour
Rate
kWh
20.5 in (520 mm) 18 13 600 21.3
25.0 in (635 mm) 18 15 700 24.8
Battery Compartment Cells Plates
Ah @ 6-hour
Rate
kWh
20.5 in (520 mm) 24 11 340-400 15.8-18.6
25.0 in (635 mm) 24 15 425-500 19.8-23.3
