3-46 Operator Controls
Mini Lever (optional)
1) Forward and Reverse switch
Switch for shifting between forward
and reverse.
Forward : Push forward
Reverse : Push backward
The speed of forward and backward
traveling can be adjusted by pressing
the accelerator pedal.
• Stop the vehicle before shifting between forward and backward
traveling.
• Always operate the control switch from a properly seated posi-
tion.
2) Lift Lever
Raise and lower the forks for loading.
Raise : Pull backward
Lower : Push forward
Raising speed can be adjusted by
the extent of pulling the lift lever.
Lowering speed can be adjusted by
the extent of pushing the lift lever.
• If you leave the seat while lowering the lift lever, the forks will not
descend due to the operators presence feature. This applies to
all hydraulic functions.
