CDM-20 Page-9
2.1 POWER SWITCH
A push - push switch is used to turn the meter on or off.
2.2 DISPLAY
3 ½ digit, 7 segment, 18mm high LCD.
2.3 FUNCTION AND RANGE SELECTOR
There are different functions and 32 ranges provided. A rotary switch is used to select functions and ranges.
2.4 INPUT JACKS
1. “COM” jack - Plug in connector for black (negative) test lead
2. “V/Ω” jack - Plug in connector for red (positive) test lead for voltage and resistance.
3. “2A” jack - Plug in connector for red test lead for current (2A MAX).
4. “10A” jack - Plug in connector for red test lead for 10A measurement.
