CDM-20 Page-19
4.5 AC CURRENT
Range Accuracy Resolution
20µA ±3.0% of rdg + 7digits l0nA
200µA 0 .1µA
2mA ±1.0% of rdg + 3digits 1µA
20mA 10µA
200mA ± 1.8% of rdg 3 digits 100µA
2A 1mA
10A ± 3.0% of rdg + 7 digits l0mA
Max Input Current: 2A2A. 10A10A continuous, .20A 15 sec MAX
Overload Protection: 2A/250V fuse (10A range unfused); Frequency Range 40Hz to 1kHz
Indication: Average (rms of sine wave) Measuring Voltage Drop 200mV
