CDM-20 Page-18
4.4 DC CURRENT
Range Accuracy Resolution
20µA ± 2.0 % of rdg+ 5 digits 10nA
200µA 0.1µA
2mA ±0.8% of rdg + 1 digits 1µA
20mA 10µA
200mA ± 1.2 % of rdg ± 1 digits 100µA
2A 1mA
10A ±2.0% of rdg + 5 digits l0mA
Max Input Current: 2A:2A. 10A:10A continuous, 20A 15 sec.MAX.
Overload Protection: 2A/250V fuse (10A range unfused); Measuring Voltage Drop: 200mV
