CDM-20 Page-17
4.3 AC VOLTAGE
Range Accuracy Resolution
200mV ±1.2 % of rdg + 3 digits 100µV
2V 1 mV
20V ±0.8 % of rdg + 3 digits 10mV
200V l00mV
700V ±1.2% of rdg + 3 digits 1V
Input Impedance: 10MΩ on all ranges.
Frequency Range: 40Hz to 1 kHz; Indication: Average (rms of sine wave).
Overload Protection: 250V rms AC for 200mV range and 1000V DC or 700V rms AC for other ranges.
