No. Description Part No. Qty
No. Description Part No. Qty
1 Motor SD45001 1
2 Motor Pulley SD45002 1
2A Motor Pulley Grubscrew SD45002A 1
3 Motor Pulley Cover SD45003 1
4 Micro Switch SD45004 1
5 Motor Mounting Plate SD45005 1
6 Gearbox Cover SD45006 1
7 Gearbox Cover Gasket SD45007 1
8 Gearwheel SD45008 1
8A Gearwheel Shaft SD45008A 1
9 Ball Bearing SD45009 2
10 Oil Seal SD45010 2
11 Bearing Bush SD45011 1
12 Wheel Brg Cover Plate SD45012 1
13 Blade Wheel (G/Box) SD45013 1
14 Thrust Washer SD45014 1
15 Gearbox Pulley SD45015 1
15A Gbox Pulley Grubscrew SD45002A 1
16 Belt SD45016 1
17 Washer SD45017 1
18 Wheel Brg Cover Plate SD45018 1
19 Bearing Bush SD45019 1
20 Ball Bearing SD45020 2
21 Worm Gear SD45021 1
22 Blade Tens. Slide Guide SD45022 2
23 Blade Tension Slide Plate SD45023 1
24 Shaft Block SD45024 1
25 Sliding Plate Draw Block SD45025 1
25A Blade Wheel Shaft SD45025A 1
26 Spring SD45026 1
27 Blade Tension Adjuster SD45027 1
28 Micro Switch SD45028 1
29 Switch Cut-Off SD45029 1
30 Adjustable Bracket Right SD45030 1
30A Adjustable Bracket Left SD45030A 1
31 Blade Adjustable Seat SD45031 2
32 Bearing Shaft Pin SD45032 2
33 Guide Pivot SD45033 4
34 Hex Nut SD45034 4
35 Bearing SD45035 6
36 Hex Nut SD45036 4
37 Blade Guard Right SD45037 1
38 Blade Guard Left SD45038 1
39 Vertical Cutting Plate SD45039 1
40 Vert Cutting Plate Supp’t SD45040 1
41 Bush SD45041 1
42 Blade Wheel Left SD45042 1
43 Blade Brg Guide Lock SD45043 2
44 Safety Cover Screw SD45044 1
46 Safety Cover SD45045 1
45 Saw Blade SD45046 1
47 Adjusting Rod SD45047 1
48 Adjusting Rod Support SD45048 1
49 Nut Plate SD45049 1
50 Spring Adjuster Screw SD45050 1
51 Spring SD45051 1
52 Pivot SD45052 1
53 Pivot Rod SD45053 1
54 Mitering Vice Plate SD45054 1
55 Moveable Vice Plate SD45055 1
56 Vice Nut SD45056 1
57 Lead Screw SD45057 1
58 Vice Adjuster Handle SD45058 1
59 Circlip SD45059 1
60 Switch Panel SD45060 1
61 Left Leg SD45061 1
62 Right Leg SD45062 1
63 Tool Tray SD45063 1
64 Bolt Hex SD45064 4
65 Flat Washer SD45065 4
66 “D” Washer SD45066 4
67 Nut Hex SD45067 4
68 Handle SD45068 1
69 Split Pin SD45069 2
70 Wheel SD45070 2
71 Wheel Bracket SD45071 1
72 Axle SD45072 1
73 Cable SD45073 1
74 Body Frame Lock Plate SD45074 1
75 Body Frame SD45075 1
76 Bed SD45076 1
77 Work Stop Rod SD45077 1
78 Work Stop SD45078 1
78A Work Stop Grubscrew SD45002A 1
79 Cable SD45079 1
Parts List
18
