• When reversing the motor, ensure that the motor has stopped fully
before doing so.
• For some applications of small motors or motors of unusual magnetic
characteristics, it may be necessary to provide a pilot motor to obtain a
balance of phases. Generally the pilot motor should be a 2 pole (2800
rpm) motor and as a general guide should be at least twice as big as
the motor to be driven.
If necessary, consult a qualified technician.
COMPONENT PARTS LIST
No Description Suppliers No
1 Front Frame EM21690425
2 D.38 Knob for Red Switch + Indicator EM04600268
3 Green Pilot-lamp 220V+Rules L=230 EM2261000
4 Circuit Breaker 20A EM22210018
5 Ammeter 20A F540 EM22600046
6 Capacitor MKM 5MF 450V 35x4 EM22315025
6 Capacitor MKM 8MF 450V 30x78 EM22315026
6 Capacitor MKM 10MF 450V EM22315027
6 Capacitor MKM 16MF 450V 45x80 EM22315028
6 Capacitor MKM 40MF 450V EM22315031
7 Relay LY2 24VDC EM22225318
8 Capacitor 4.7mf-63V SX11 P-2 EM26000005
8 W10 Rectifier EM26014005
9 Plastic Handle EM21600030
10 Cover Panel for large converter EM33705461
11 Switch 12A ON/OFF EM22205009
12 Orange Pilot Lamp 220V EM22610013
13 Double Pole Black Switch EM22200043
14 Input Cable 3x1,5 M2,5 EM20220014
15 Cable Clamp D.10+ Screw EM04600234
16 CEE 16A 380V 3pH Socket + Panel Earth EM22105067
17 Front Panel EM33710373
18 Rear panel EM33715123
