SPECIFICATIONS
PG3800A
Engine Engine Model PT170F1
Fuel Type Petrol
Displacement (cm
3
)
212 cc
Max. power output (hp/rpm) 5.6 @ 3000 rpm
Start system Hand recoil
Fuel tank capacity (L) 15
Fuel consumption (L/hr.) 1.9
Maximum run time (h) @75% Load 8.2
Engine oil type SAE15W40
Engine oil capacity (L) 0.61
Guaranteed sound power (L
WA dB) 96
Generator Rated Frequency (Hz) 50
AC Output Voltage (V) 230 (13A)
DC Output Voltage (V) 12V (Max 8.3A)
Rated Power (W) 2700
Dimensions Length (mm) 600
Width (mm) 435
Height (mm) 445
Unpacked Weight (kg) 43.7
