Clarson PUBLIC IV - Page 4

6 7
Control Room
Intercom System
without footswitch
4
H
C
C
N
Installaon Loudspeaker
Paent´s Room
20m
20m
1m
3
3a
> Intercom Speaker
< Intercom Connecon Hub (3)
> Intercom Connecon Hub (3)
< Intercom Speaker
4
4a
2m
3m
2
2a
1b
4a
3b
> Intercom Power Supply
< Intercom Cleaner Socket
> Intercom Cleaner Socket
< Intercom Power Supply
> Intercom Connecon Hub (1)
< Intercom Console (1)
> Intercom Console (1)
< Intercom Connecon Hub (1)
1
1a
2
2a
> Intercom RJ45 Connector (1)
< Intercom Microphone
3
> Intercom R45 Connector (2)
< Intercom Connecon Hub (2)
3a
> Intercom Connecon Hub (2)
< Intercom R45 Connector (2)
3b
> Intercom Connecon Hub (6)
(DC Power)
< Intercom Power Supply
15V /700mA
1b
Ceiling installaon microphone
6 5
3 8
5
drilling template
J
Important for Installaon Planning:
Dimensions microphone cable :
Length 1m, Ø 3,1mm
Extension cable length 20m, Ø 5,5mm
Clearance hole for RJ45 connector
minimum Ø16mm.
Observe drilling template!
Dimensions loudspeaker cable:
Length 20m, Ø 5,5mm
Clearance hole for RJ45 connector
minimum Ø17mm.
Dimensions mounng material
see page 4
Wandsteckdose
100-240V
50-60Hz
~
wall socket
100-240V
50-60Hz
~
No other power supply than the one tested and appro- ved by Clarson must be used.
1a
1
