Clay Paky Mini-B - Mains Power Connection

4
Mini-B
Mains
5
Connecting to the mains supply
- Fig. 5
1
2
3
2
1
1
2
3
2
1
4
Connecting and disconnecting power cable - Fig. 4
NB: connecting one
Mini-B to the mains,
it is possible to connect
up to a maximum
of 6 @200-240Vac -
2 @100-120Vac Mini-B in
parallel at the same time.
F
use 5x20mm
6
.3AT 250V
(030463)
P
ower in
(
NAC3MPX,
Neutrik)
D
MX in
(
NC5MAV,
Neutrik)
E
thernet
(RIX8FA3VB,
Amphenol)
P
ower out
(
NAC3MPX,
Neutrik)
D
MX out
(NC5MAV,
Neutrik)
L
CD Display
Functional buttons
3
Control Panel - Fig. 3
3
.2 Connecting to manis supply
