GLOW UP
7
4
3
1
2
1
2
Fuse 6,3x32mm
10AT 250Vac
(030470)
Fuse 6,3x32mm
3AT 250Vac
(030471)
9
8
Charging glow up - Fig. 8
From 1 to 6 Glow Ups can be simultaneously charged by appropriately connecting and powering the flight-case.
Replacing flight case fuses - Fig. 9
Each flight-case has 2 fuses associated with the main power cord connection and one fuse for each Glow UP charge station.
