PLUMBING ASSEMBLY (P. 1)
REF
PART NO.
DESCRIPTION
NOTES:
1
263-040
Hose ASSM, Temp(CV) C-Panel 3/8 X 19-1/2"
2
360-206
Sender, Temp-Electronic
3
415-135
FW, 3/8" SS
4
415-137
FW, 3/8" AN SS
5
415-155
FW, 1/2" SS
6
415-156
FW, 1/2" Military
7
415-157
FW, 1/2" AN SS
8
415-165
FW, 5/8" SS
9
425-115
Clamp, Hose Silicone
10
480-015
PVC Tubing, 3/8" ID Clear
11
530-105
Pulsar Unloader
12
551-020
Valve, Temp Control
13
551-075
Vac Lube Port
14
555-002
ADPT, 1/4 M x 1/4 F
15
555-022
Bushing, 3/8 M x 1/8 F
16
555-074
Closed Nipple, 3/8"
17
555-132
Coupling, 1/4"
18
555-180
Elbow 45, 1/8" Street Extruded
19
555-184
Elbow 45, Street 1/4"
20
555-186
Elbow 45, 3/8" Street Extruded
21
555-204
Elbow 90, 1/8" Street Forged
22
555-206
Elbow 90, 1/4" FPT Extruded
23
555-208
Elbow 90, 1/4" Street Extruded
24
555-212
Elbow 90, 3/8" FPT
25
555-214
Elbow 90, 3/8" Street Extruded
26
555-242
Extruded Cross, 3/8"
27
555-252
Ferrule, 1/4 Nylon Braid
28
555-274
Hex Nipple, 3/8"
29
555-320
Hose Barb 90, 1/4 Barb X 1/8 MPT
30
555-324
Hose Barb 90, 3/8 Barb X 1/4 MPT
31
555-350
Hose Barb, 1/4 Barb X 1/8 MPT
32
555-364
Hose Barb, 3/8 Barb X 1/4 MPT
33
555-390
Hose Barb, 5/8 Barb X 3/8 MPT
34
555-430
Long Nipple, 3/8 X 1-1/2 "
35
555-434
Long Nipple, 3/8 X 2"
36
555-454
Plug, 3/8 MPT Hex Head
37
555-456
Plug, 3/8" MPT (Countersunk)
38
555-543
Reducing Nipple, 3/8 MPT X 1/4 MPT Stainless S.
39
555-636
Tee, 1/4" Street Extruded
40
555-640
Tee, 3/8" FPT.
41
560-110
Brass Filter Check Valve 1/4"
42
572-100
Clear Braided Hose 1/4”
43
572-125
Pulse Hose, 3/8"
44
580-010
Q.C. 1/4" Fem (Closed)
