Cleanco Compact 45 - CAD Panel Mount Option

56
CAD PANEL MOUNT OPTION
REF
PART NO.
DESCRIPTION
NOTES:
1
415-195
FW, 1” S.S.
2
545-035
Ball Valve 3/4"
3
555-025
Cap Nut
4
555-079
Close Nipple 3/4 short
5
555-144
Coupling, M.Hose to 3/4" FTP
6
555-222
Elbow 90, 3/4" Street Forged
7
555-278
Hex Nipple 3/4"
8
555-400
Hose Barb, 1 Barb x 3/4 MPT
9
580-170
Q.C 3/4 FEM. (Open)
10
580-175
Q.C 3/4 Male (Open)
